What capsules does the HM1000 M work with?

The HM1000 M is compatible with all DAM+ Series capsules, including the CK41, CK43, and CK49. It integrates with the full DAM+ Series phantom power ecosystem for seamless modular operation.

What's included in the box?

The module includes the HM1000 M hanging unit, a spring steel hanging clamp for vibration isolation, a 10 m special cable with temperature-resistant anti-twist design, and an integrated LED ring that displays microphone status.

How does the bass cut filter help?

The switchable 250 Hz bass cut filter reduces low-end rumble and proximity buildup, helping you control feedback and boost presence in live or studio settings without needing external EQ.

What are the physical dimensions and weight?

The module measures 50 mm in height and 13.5 mm in diameter, weighing just 184 g (6.49 oz), making it lightweight enough for secure rigging while minimizing mechanical load on suspension systems.

Is the cable connector proprietary?

Yes, the HM1000 M uses a tapered connector (9 mm top, 11.3 mm bottom) designed specifically for the DAM+ Series phantom power ecosystem. The 10 m cable is engineered to resist twisting across temperature variations.

AKG HM1000 M Reference Hanging Module

The AKG HM1000 M Reference Hanging Module is a professional-grade condenser microphone suspension system engineered to capture every nuance of your performance with pristine clarity. Its elegant hanging design allows you to dial in exact proximity and angle, bringing out warmth and articulation from vocals and instruments alike. Built for gigging musicians and touring productions, this reference-grade module delivers transparent, detailed sound that won't color or compromise your tone on stage or in the studio.

Design & Build Quality

The module measures 50 mm in height with a compact 13.5 mm diameter, weighing just 184 g so it won't burden your rig or rigging systems. A spring steel hanging clamp and integrated LED ring expander are included, offering visual status feedback at a glance with matte black finish that keeps the focus on your sound, not the gear.

Connectivity & System Integration

A 10 m (33 ft) special cable resists twisting across temperature variations, staying reliable through road cases and venue changes with a tapered connector design (9 mm top, 11.3 mm bottom) that integrates with the full DAM+ Series phantom power ecosystem. The recommended load impedance of 2000 Ohms and switchable 250 Hz bass cut filter let you shape your signal for any stage or recording scenario without losing presence or introducing feedback.

Key Features

Compatible with all DAM+ Series capsules (CK41, CK43, CK49)
Spring steel hanging clamp included for secure, vibration-isolated suspension
Integrated switchable LED ring displays microphone status at a glance
10 m special cable with temperature-resistant anti-twist design
Tapered connector: 9 mm (top) / 11.3 mm (bottom) diameter
Integrated system connector compatible with all DAM+ Series phantom power modules
Bass cut filter at 250 Hz for presence and feedback control
Recommended load impedance: 2000 Ohms
Compact dimensions: 50 mm height × 13.5 mm diameter
Lightweight construction at 184 g (6.49 oz)
Professional matte black finish
Reference-grade audio transparency for studio, broadcast, and live applications

The HM1000 M combines modular flexibility with studio-standard transparency, making it the go-to choice for musicians and venues demanding professional-grade miking without compromise.
