AKG PCC130 SW High Performance Boundary Layer Microphone

AKG PCC130 SW High Performance Boundary Layer Microphone

The AKG PCC130 SW is a compact boundary layer condenser built to capture your performance with pristine audio, minimal proximity coloration, and rejection of unwanted room noise. Its cardioid pattern and electret-condenser capsule deliver crystal-clear reproduction across vocals, acoustic instruments, and amplified sources, making it equally reliable for live reinforcement, studio tracking, and broadcast work. The satin black finish and low-profile form factor stay visually out of the way while delivering professional-grade signal integrity gig after gig.

Audio Performance

This microphone delivers a smooth, extended frequency response spanning 50–20,000 Hz, capturing full acoustic detail from bass warmth to pristine high-frequency clarity in your tone. A 72 dB-A signal-to-noise ratio and 22 dB-A equivalent noise level ensure transparent reproduction in quiet environments, while the 120 dB SPL maximum handles everything from intimate solos to full ensemble reinforcement without distortion or breakup.

Design & Controls

Measuring just 89 × 64 × 25 mm, the PCC130 SW mounts flush to surfaces for discreet placement and optimized boundary layer pickup that works seamlessly on stage or in the studio. The three-position bass-tilt switch lets you dial in low-end response on the fly, while the programmable membrane switch offers silent touch activation, momentary on, or momentary off modes—ideal for hands-free operation during live performances. A high-intensity LED indicator provides visual feedback, and the included 15-foot two-conductor shielded cable with TA3F and XLR connectors ensures professional-grade signal integrity you can count on night after night.

Key Features

• Electret-condenser capsule with cardioid boundary layer polar pattern
• Audio frequency bandwidth: 50–20,000 Hz
• Signal-to-noise ratio: 72 dB-A
• Equivalent noise level: 22 dB-A
• Sensitivity: 22 mV/Pa
• Maximum SPL: 120 dB (without distortion)
• Dimensions: 89 × 64 × 25 mm (compact flush-mount form factor)
• 12–48 V phantom power operation
• Three-position bass-tilt switch for low-end response control
• Silent-operating programmable membrane switch with touch, momentary on, and momentary off modes
• High-intensity LED indicator
• Switchcraft TB3M connector with included 15-foot TA3F to XLR cable
• Satin black finish

The PCC130 SW combines transparency, control, and live reliability—essential qualities for any player or engineer demanding pristine audio reproduction and professional durability in critical listening and reinforcement applications.
