AMX DX-TX-DWP-4K60-BL DXLink 4K60 HDMI Wallplate Transmitter, Black
Description
AMX DX-TX-DWP-4K60-BL DXLink 4K60 HDMI Wallplate Transmitter, Black
The AMX DX-TX-DWP-4K60-BL is a professional-grade HDMI transmitter designed to integrate seamlessly into standard wall installations, delivering high-fidelity video and audio over extended distances via standard network cabling. This compact wallplate transmitter handles 4K resolution and advanced color depths, making it essential for live venues, touring rigs, conference installations, and distributed video systems where clean cable runs and reliable signal integrity are non-negotiable.
Video & Signal Transmission
This transmitter delivers 4K60 4:4:4 video with HDMI 2.0 and HDCP 2.2 compliance, ensuring compatibility with modern displays and content protection standards. HDR10 support and 36-bit Deep Color processing preserve color accuracy and dynamic range across extended cable runs of up to 131 feet using standard Cat6a or Cat7 shielded twisted-pair cable—critical for touring operations and permanent installations alike.
Connectivity & Integration
Audio, video, and USB 2.0 signals travel over a single shielded network cable, eliminating the need for separate runs and reducing setup time at load-in. The unit features USB-B host port, HDMI input, RJ45 DXLink output, and 3-pin Phoenix RS-232 pass-through connectivity, enabling full control integration and device management in networked AV systems, from installed venues to mobile production rigs.
Key Features
- 4K60 4:4:4 video capable with HDMI 2.0 and HDCP 2.2 support
- HDR10 support and up to 36-bit Deep Color processing
- Transmits audio, video, and USB 2.0 over a single Cat6a or Cat7 shielded twisted-pair cable
- Audio and video signals extend up to 131 feet via standard Cat6a/7 cable
- 4K60 4:4:4 transmission up to 40 meters when using Cat6a shielded cable
- Mounts in standard US single gang back box for flush wall installation
- USB-B host port and HDMI input connectivity
- RJ45 DXLink output port for networked AV systems
- 3-pin Phoenix RS-232 pass-through for control and device integration
- RS-232 baud rate fixed at 115200
- Power supplied via DXLink power-sourcing device or optional desktop power supply
The DX-TX-DWP-4K60-BL combines professional 4K video performance with practical wallplate integration, delivering the dependable signal transmission sound engineers and AV technicians rely on for live events, touring, and permanent venue installations requiring long-distance transmission over standard network infrastructure.
More Information
| Condition | New |
|---|
Reviews
At a Glance
The AMX DX-TX-DWP-4K60-BL is a professional HDMI wallplate transmitter that sends 4K60 video, audio, and USB control over a single Cat6a/7 cable up to 131 feet, ideal for conference rooms, control rooms, and distributed AV installations where clean in-wall cable runs matter. It handles HDR10 and deep color processing while integrating into standard wall boxes, and includes RS-232 pass-through for full system control. Choose this if you're building a networked AV system that demands reliability, long cable runs, and professional integration without visible cable clutter.
Who This Is For
Great for
- ✓ Conference room AV installation
- ✓ Distributed video systems
- ✓ Professional AV integration
- ✓ Control room signal distribution
Not the best pick for
- – Consumer home theater
- – Live music performance
- – Studio recording
Skill level: Professional
Frequently Asked Questions
What cable distance does this transmitter support?
The DX-TX-DWP-4K60-BL transmits 4K60 4:4:4 video, audio, and USB 2.0 up to 131 feet using standard Cat6a or Cat7 shielded twisted-pair cable. For Cat6a specifically, the 4K60 4:4:4 range is up to 40 meters.
What video formats and color depths does it support?
This transmitter delivers 4K60 4:4:4 resolution with HDMI 2.0 and HDCP 2.2 compliance, HDR10 support, and up to 36-bit Deep Color processing to maintain color accuracy and dynamic range over long cable runs.
What connections and control options are included?
The unit features HDMI input, RJ45 DXLink output, USB-B host port, and 3-pin Phoenix RS-232 pass-through for control integration. Audio, video, and USB all travel over the single DXLink cable, and the RS-232 baud rate is fixed at 115200.
How does it mount, and what power does it need?
It mounts in a standard US single-gang back box for flush wall installation. Power is supplied via a DXLink power-sourcing device or an optional desktop power supply.
Is this suitable for live sound or music performance?
No, this is a professional AV integration tool designed for conference rooms, control rooms, and distributed video systems. It is not intended for live music performance or studio recording applications.
