JBL AC895-WH 8" 2-way full-range system, white
Description
JBL AC895-WH 8" 2-Way Full-Range System, White
The JBL AC895-WH is a compact yet capable full-range speaker that delivers consistent coverage and output across venues ranging from small installations to mid-sized events. Its rotatable design and professional-grade construction make it equally at home on a pole mount or wall bracket, adapting to real-world deployment needs without compromise.
Audio Performance & Coverage
This system pairs an 8-inch woofer with a 1-inch compression driver to achieve a frequency response of 75 Hz to 18 kHz with extended range down to 70 Hz at −10 dB. The 90° by 50° coverage pattern via the PT Progressive Transition waveguide ensures even sound distribution in vertical orientation, while the highslope passive crossovers maintain clean handoff between drivers across the frequency spectrum.
Build & Mounting Flexibility
Built from 15 mm multi-ply hardwood plywood, the enclosure withstands the rigors of repeated deployment and transport. The cabinet includes M10 threaded suspension points and four threaded inserts on the back for MultiMount or similar mounting attachment, giving you reliable options for permanent or temporary installation scenarios.
Key Features
- One 209 mm (8 in) low frequency driver and one 25 mm (1 in) exit compression driver with 25 mm voice coil
- Highslope passive crossovers
- 90° by 50° coverage in vertical cabinet orientation
- Rotatable PT Progressive Transition waveguide
- Handles up to 300W program power
- Maximum SPL of 116 dB (122 dB peak)
- Frequency response of 75 Hz to 18 kHz; range of 70 Hz to 20 kHz (−10 dB)
- 15 mm multi-ply hardwood plywood enclosure
- M10 threaded suspension points
- Four threaded inserts on back for MultiMount or similar mounting attachment
- White finish
The AC895-WH combines professional audio performance with straightforward rigging and flexible mounting, making it a dependable choice for venues where consistent sound and reliable output are essential to your show.
More Information
| Condition | New |
|---|
Reviews
At a Glance
The JBL AC895-WH is a compact 8-inch 2-way full-range speaker designed for live sound in small-to-mid venues, installations, and corporate events. Its rotatable waveguide, sturdy plywood construction, and 116 dB max SPL deliver even coverage and clean audio whether pole-mounted or wall-bracketed. Choose this system when you need road-tested reliability, flexible rigging, and consistent output without bloat.
Who This Is For
Great for
- ✓ Live Performance
- ✓ Small-to-mid venue PA
- ✓ Installation audio
- ✓ Conferencing/install
Not the best pick for
- – Home hi-fi listening
- – Studio nearfield monitoring
Skill level: Intermediate · Advanced · Professional
Frequently Asked Questions
What is this speaker designed for, and what is it not?
The AC895-WH is built for live performance PA, small-to-mid venue systems, installation audio, and conferencing. It is not intended for home hi-fi listening or studio nearfield monitoring where proximity and flat response at close range are critical.
How does the mounting work, and can it be wall-mounted or pole-mounted?
The cabinet includes M10 threaded suspension points for pole mounting and four threaded inserts on the back for MultiMount or similar bracket attachment, supporting both temporary and permanent installation scenarios.
What is the frequency response and maximum output?
The AC895-WH covers 75 Hz to 18 kHz (70 Hz to 20 kHz at −10 dB) with a maximum SPL of 116 dB and peak SPL of 122 dB, handling up to 300W program power.
How does the waveguide coverage pattern work?
The rotatable PT Progressive Transition waveguide provides 90° by 50° coverage in vertical orientation, ensuring even sound distribution across the listening area and clean handoff between the 8-inch woofer and 1-inch compression driver via highslope passive crossovers.
Is this speaker built to handle touring and repeated setup/teardown?
Yes. The cabinet is constructed from 15 mm multi-ply hardwood plywood designed to withstand repeated deployment and transport, making it reliable for gigging and venue-to-venue work.
