JBL Control 65P/T-WH 5.25" PREMIUM RBI PENDANT SPK W RBI, WHT
Share
- Brand new in original box
- Full JBL manufacturer's warranty
- Free shipping in the continental US
Out of stock
- SKU
- C65P-T-WH
Description
JBL Control 65P/T-WH 5.25" Premium RBI Pendant Speaker with RBI, White
The Control 65P/T-WH is a compact coaxial pendant speaker engineered for suspended ceiling installations in commercial and institutional spaces. Its lightweight construction and patent-pending Radiation Boundary Integrator (RBI) technology deliver focused, controlled acoustic projection without the beaming and phase issues typical of conventional ceiling speakers. The white finish integrates seamlessly into standard drop-ceiling environments while maintaining professional audio fidelity.
Acoustic Performance & Coverage
This speaker produces 86 dB nominal sensitivity with a rated maximum SPL of 105 dB continuous (111 dB peak), delivering articulate speech and balanced music reproduction across commercial environments. The 120° nominal coverage angle ensures even sound distribution throughout mid-sized rooms, while RBI waveguide technology — adapted from JBL's VERTEC line arrays — minimizes phase distortion and acoustic dead zones common in pendant installations.
Reliability & Installation
The 130 mm coaxial driver arrangement pairs a polypropylene-coated LF cone with a neodymium 20 mm textile soft-dome HF driver featuring ferro-fluid cooling for extended reliability. Robust High Impact PolyStyrene (HIPS) construction with steel and rubber components stands up to the demands of permanent installations and frequent venue use, while the compact 234 mm diameter footprint and 3.7 kg weight simplify handling and ceiling mounting.
Key Features
- 130 mm (5.25-inch) low-frequency driver with polypropylene-coated cone and copper voice coil
- 20 mm (3/4-inch) textile soft-dome tweeter with neodymium magnet and ferro-fluid cooling
- Coaxially mounted driver configuration for time-aligned output
- Patent-pending Radiation Boundary Integrator (RBI) with 200 mm diameter waveguide
- 75 Watts continuous pink noise (150 Watts program), 300 Watts peak power handling
- 8-ohm rated impedance
- 60W multi-tap 70V/100V transformer with six selectable taps (60W, 30W, 15W, 7.5W)
- Frequency response: 55 Hz – 20 kHz (-10 dB); 78 Hz – 18 kHz (±3 dB)
- Maximum SPL: 105 dB continuous, 111 dB peak at 1 meter
- 120° nominal coverage angle with ±20°/-10° characteristics
- Two removable locking euro-block connectors with screwdown terminals
- Compact 234 mm diameter, 259 mm height; 3.7 kg weight
The Control 65P/T-WH combines architectural integration with advanced acoustical engineering, making it the choice for installations where consistent sound coverage and minimal visual impact are equally important.
More Information
| Condition | New |
|---|
Reviews
At a Glance
The JBL Control 65P/T-WH is a compact 5.25" coaxial pendant speaker built for suspended-ceiling commercial and institutional spaces, delivering articulate speech and balanced sound across mid-sized rooms without the phase issues and dead zones typical of standard ceiling speakers. Its patent-pending RBI waveguide technology (borrowed from JBL's touring line arrays) ensures controlled, focused projection with 120° coverage and a clean white finish that disappears into any drop-ceiling environment. Choose this if you're installing sound in retail, conference rooms, schools, or offices where speech clarity, even coverage, and minimal acoustic interference matter more than high-SPL music playback.
Who This Is For
Great for
- ✓ Commercial install
- ✓ Conferencing
- ✓ Retail environments
- ✓ Institutional spaces
Not the best pick for
- – Live sound reinforcement
- – High-SPL music venues
Skill level: Beginner · Intermediate · Advanced · Professional
Frequently Asked Questions
What is RBI technology and how does it improve sound?
RBI (Radiation Boundary Integrator) is JBL's patent-pending waveguide system adapted from their VERTEC touring line arrays. It minimizes phase distortion and eliminates acoustic dead zones common in conventional pendant speakers, delivering focused, controlled projection with no beaming.
Is this speaker suitable for high-volume music playback or live events?
No. The Control 65P/T-WH is engineered for commercial speech reproduction and balanced music in institutional spaces—retail, offices, and conferencing—not live sound reinforcement or high-SPL music venues.
What mounting and power options does it have?
It mounts in standard suspended ceilings via a compact pendant bracket (234 mm diameter). Power is handled by a 60W multi-tap 70V/100V transformer with six selectable taps (60W, 30W, 15W, 7.5W), allowing flexible installation across different circuit loads.
What is the frequency response and maximum SPL?
Frequency response is 55 Hz–20 kHz (−10 dB) and 78 Hz–18 kHz (±3 dB). Maximum SPL is 105 dB continuous or 111 dB peak at 1 meter, delivering sufficient headroom for articulate speech and music without distortion in mid-sized rooms.
How much space does it take up and how heavy is it?
The Control 65P/T-WH measures 234 mm in diameter and 259 mm in height, weighing only 3.7 kg, making it easy to handle and install in tight ceiling cavities while maintaining a minimal visual footprint.
