JBL CSS-H30-BK 30W Paging Horn W Transformer Black

JBL CSS-H30-BK 30W Paging Horn with Transformer – Black

The CSS-H30-BK is a compact, weather-resistant paging horn built for consistent vocal clarity and reliable outdoor performance on the road or at a fixed venue. Its compact footprint and stainless steel U-bracket mount quickly to walls, poles, or scaffolding without demanding extensive infrastructure work. The integrated transformer and multi-tap configuration mean you're ready to rig and go—no external gear required to get professional results on day one.

Coverage & Audio Performance

This horn delivers 108 dB sensitivity at 1W (peaking at 112 dB at 1.4 kHz), capable of sustaining 123 dB continuous average SPL with 129 dB peak output. The 50° × 70° coverage pattern ensures even sound distribution across typical announcement zones while the built-in 350 Hz high-pass filter cuts through low-frequency rumble, keeping speech intelligible in noisy live settings.

Power & Installation Flexibility

The UL-registered 30W multi-tap transformer works with both 70V and 100V system configurations, offering selectable taps at 30W, 15W, 7.5W, 3.8W, and 1.9W, plus an 8-ohm direct bypass mode for quick integration into existing rigs. The 12-inch pigtail with bare wire connection and watertight fitting entrance speed up field wiring while the IP65-rated ABS enclosure stands up to moisture, dust, and UV exposure in any climate or venue.

Key Features

• 30W system power rating (120W peak) with UL-registered transformer
• 108 dB sensitivity (1W, 2.83V @ 1m, 1 kHz–6 kHz average); 112 dB at 1.4 kHz
• 123 dB continuous average SPL (129 dB peak); 127 dB continuous at 1.4 kHz (133 dB peak)
• Frequency response: 380 Hz – 6 kHz (–10 dB)
• 50° horizontal × 70° vertical coverage pattern
• Multi-tap transformer: 70V/100V compatible with 30W, 15W, 7.5W, 3.8W, and 1.9W settings plus 8-ohm bypass
• 1.5-inch passive full-range driver with phenolic diaphragm
• Built-in 350 Hz high-pass filter for enhanced speech clarity
• IP65-rated weather-resistant ABS enclosure with stainless steel mounting bracket
• Compact dimensions: 8.9" H × 11.2" W × 11.3" D (224 × 285 × 287 mm)
• 12-inch pigtail with bare wire connections and watertight fitting entrance
• Directivity Index: 12 at 2 kHz for controlled, focused sound projection

The CSS-H30-BK delivers dependable, high-output paging performance with transformer flexibility and weather durability built into a space-efficient design that works for touring, fixed installations, and everything in between.
