Martin Exterior Projection Pro Compact Black
Description
Martin Exterior Projection Pro Compact Black
The Martin Exterior Projection Pro Compact Black is a professional-grade LED projection fixture built for outdoor installations where durability and optical precision are non-negotiable. Its compact form factor and motorized control system make it equally at home on building facades, landscape features, or temporary event structures, delivering consistent performance in demanding environmental conditions.
Optical Performance & Control
Powered by a 130W 7500K LED producing 4,700 lumens, this fixture delivers daylight-balanced output suitable for architectural and theatrical applications. The motorized focus system adjusts from 3 meters to infinity, while the built-in zoom mechanism spans 15° to 45° projection angles, allowing precise beam shaping without lens changes. DMX and RDM control via Martin Companion programming give operators full command over focus, zoom, and effect layering during live events.
Built for Venue & Road Reliability
Cast aluminum housing with hard anodized finish and 5 mm anti-reflection coated tempered glass create a sealed, corrosion-resistant enclosure rated IP66 for complete dust and water protection. The fixture carries IK08 impact resistance and C5 corrosion resistance (ISO 12944), making it suitable for coastal and industrial environments. Hibernation power mode via DMX lets crews power down between show segments without full shutdown.
Key Features
- 130W 7500K LED with 4,700 lumens output
- Motorized focus: 3 meters to infinity
- Built-in zoom: 15° to 45° projection angle
- IP66 ingress protection rating
- IK08 impact resistance
- C5 corrosion resistance (ISO 12944)
- Cast aluminum housing with hard anodized finish
- 5 mm anti-reflection coated tempered glass front
- DMX, RDM, and magnetic switch control with Martin Companion programming
- Hibernation power mode via DMX
- 11 configurable options with up to four layers of effects
- Optional modules: manual framing, animation, gobo holders
- 5-year warranty
This fixture's sealed construction, advanced optics, and comprehensive control options make it a reliable workhorse for permanent and semi-permanent outdoor projection applications where equipment dependability is mission-critical.
More Information
| Condition | New |
|---|
Reviews
At a Glance
The Martin Exterior Projection Pro Compact Black is a professional LED projection fixture built for outdoor architectural, theatrical, and event applications where weather resistance and optical precision matter. Its 130W 7500K LED delivers 4,700 lumens with motorized focus and zoom control, sealed IP66 construction, and corrosion resistance rated for coastal and industrial environments. Choose this for permanent or semi-permanent installations on building facades and landscape features where durability and consistent daylight-balanced output are non-negotiable.
Who This Is For
Great for
- ✓ architectural projection
- ✓ outdoor events
- ✓ theatrical lighting
- ✓ permanent installations
Not the best pick for
- – portable/mobile applications
- – budget-constrained projects
- – indoor studio use
Skill level: Professional
Frequently Asked Questions
What makes this fixture suitable for outdoor use?
The Martin Exterior Projection Pro features IP66 ingress protection (complete dust and water resistance), IK08 impact resistance, and C5 corrosion resistance per ISO 12944, making it rated for coastal and industrial environments. Its cast aluminum housing with hard anodized finish and 5 mm anti-reflection coated tempered glass create a fully sealed, weatherproof enclosure.
Can I adjust the beam size and focus without changing lenses?
Yes. The motorized focus system adjusts from 3 meters to infinity, and the built-in zoom mechanism spans 15° to 45° projection angles, allowing you to shape the beam precisely without lens changes.
What control options are available?
The fixture supports DMX, RDM, and magnetic switch control with Martin Companion programming. It includes 11 configurable options with up to four layers of effects, plus a hibernation power mode via DMX for energy management.
Is this fixture portable or designed for permanent installations?
This fixture is engineered for permanent and semi-permanent outdoor installations on building facades and landscape features. Its sealed construction and advanced optics prioritize durability and consistent performance over portability.
What optional modules are available?
Optional modules include manual framing, animation, and gobo holders to expand the fixture's creative capabilities for architectural and theatrical projection work.
