AMX HPX-U100-BTN Single Button module for Hydraport
Description
AMX HPX-U100-BTN Single Button Module for Hydraport
The HPX-U100-BTN is a compact control module built for integration into AMX Hydraport systems. This single-button interface provides tactile feedback through its illuminated pushbutton, giving you reliable visual confirmation and dependable closure signaling in live sound and AV control environments. Built for quick deployment and real-world reliability, it's designed to function under the demands of professional installations.
Control Interface & Connectivity
The module features dual 2-position Phoenix connectors—one dedicated to the push-button closure circuit and one for the LED indicator. This connector-based design enables fast integration into modular Hydraport systems without permanent wiring, simplifying setup and reconfiguration between venues or system configurations. The separation of button and LED circuits allows independent control of visual feedback, letting you customize indicator behavior to your workflow.
Power & Operating Specifications
The LED back-light accepts +12 VDC nominal input with an operating range of 8–18 V, accommodating the voltage variations you encounter across different venues and power-supply setups. This wide input range ensures the indicator stays reliable even when powering complex AV systems from varying control voltage supplies common in professional touring and installed environments.
Key Features
- Single push-button with LED back-light indicator
- 2-position Phoenix connector for push-button closure
- 2-position Phoenix connector for LED input
- LED input voltage: +12 VDC nominal
- LED input voltage range: 8–18 V
- Designed as 1 HydraPort Unit module
- Single Button Module configuration
- Modular form factor for Hydraport integration
- Illuminated pushbutton for visual feedback
- Quick-disconnect Phoenix connectors for rapid installation
The HPX-U100-BTN delivers straightforward, dependable push-button control with integrated status indication—the kind of building block you need for scalable, road-ready AMX Hydraport-based control systems.
