Martin RUSH CS300 Wide RGB Color Mixing Linear Wash

Martin RUSH CS300 Wide RGB Color Mixing Linear Wash

The RUSH CS300 Wide is a compact, high-output LED cove lighting fixture engineered for seamless indoor installation. Its compact 303 mm length and 46 mm width allow integration into tight architectural spaces, while the 124° beam angle delivers broad, even illumination across walls and surfaces. This fixture combines professional performance with straightforward installation, making it a practical choice for lobbies, lounges, and other interior environments requiring flexible color mixing.

Light Output & Performance

Equipped with Cree XP-E2 RGB LEDs, the CS300 Wide delivers high-output color mixing with a 50,000-hour minimum LED lifetime (to >70% luminous output), ensuring reliable long-term operation. The 124° beam angle produces wide coverage suitable for cove installations and accent lighting without excessive point-source shadows.

Installation & Build Quality

The fixture's aluminum housing with clear anodized finish and frosted polycarbonate lens provide durable construction rated IP20 for indoor environments. At just 0.8 kg (1.8 lbs.) and measuring 303 mm × 46 mm × 57 mm, the CS300 Wide mounts directly using included brackets in any orientation, with a minimum 0.2 m clearance to illuminated surfaces required.

Key Features

• Light source: Cree XP-E2 RGB LEDs
• Beam angle: 124°
• LED lifetime: 50,000 hours (to >70% luminous output)
• Length: 303 mm (11.9 in.)
• Width: 46 mm (1.8 in.)
• Height with bracket: 57 mm (2.2 in.)
• Weight: 0.8 kg (1.8 lbs.)
• Housing: Aluminum with clear anodized finish
• Lens: Frosted polycarbonate
• Ingress protection: IP20
• AC power: 100-240 V nominal, 50/60 Hz; Maximum consumption: 485 W
• DMX control via 5-pin XLR; 6-pin custom connectors for DC power and data

The RUSH CS300 Wide delivers professional-grade color mixing in a compact, cost-effective package sized for flexible installation across a broad range of interior architectural applications.
