AMX MCP-106L-WH Massio™ 6-Button ControlPad - White - Landscape
Description
AMX MCP-106L-WH Massio™ 6-Button ControlPad - White - Landscape
The AMX MCP-106L-WH is a professional control interface built for live venues, installed sound systems, and permanent AV setups. Its compact landscape format fits standard wall-mount installations, with responsive backlit buttons that give instant visual feedback during operation. This 6-button ControlPad handles reliable command input across networked environments with minimal fuss.
Design & Installation
Measuring 3 7/16" × 4 11/16" × 9/16" (87.5 mm × 119 mm × 13.9 mm), the pad mounts directly into standard 1 gang US, UK, or EU back boxes, fitting seamlessly into existing wall infrastructure. The landscape orientation keeps buttons accessible and the interface looking professional in control rooms, venue racks, and permanent installations.
Connectivity & Control
The unit ships with a 10/100 Ethernet port with Auto MDI/MDI-X capability, supporting both straight-through and crossover cables for easy network deployment on the road or in the rack. An onboard NX-series controller with networking and security features routes commands reliably, while dedicated Serial and infrared (IR) ports let you integrate with existing control devices and legacy equipment without headaches.
Key Features
- 6 programmable buttons with independent control logic
- Backlit buttons with flash and on/off state indication
- Power over Ethernet (PoE) capable — no separate power supply required
- 10/100 Ethernet connectivity with Auto MDI/MDI-X
- Serial port for device communication
- Infrared (IR) port for remote command integration
- Mounts in standard 1 gang US, UK, or EU electrical back boxes
- Compact landscape form factor: 3 7/16" × 4 11/16" × 9/16"
- RoHS and WEEE compliant
- Onboard NX-series controller with networking and security architecture
The MCP-106L-WH combines networked intelligence, flexible I/O, and straightforward wall integration to deliver dependable control in live sound rigs, installed venues, and professional AV applications.
More Information
| Condition | New |
|---|
Reviews
At a Glance
The AMX MCP-106L-WH is a professional 6-button control pad designed for integrated AV systems, building automation, and conference room installations. It mounts flush into standard wall boxes in landscape orientation, offering backlit programmable buttons that communicate over Ethernet with PoE support and legacy Serial/IR connectivity. Choose this for permanent venue, conference, and install audio setups where reliable networked control and clean wall integration are essential.
Who This Is For
Great for
- ✓ AV system integration
- ✓ Building automation
- ✓ Conference room control
- ✓ Install audio
Not the best pick for
- – Live performance sound reinforcement
- – Home recording
- – Personal music production
Skill level: Professional
Frequently Asked Questions
What does the 6-button layout control?
Each button is fully programmable with independent control logic, so functionality depends on how your AV integrator configures them—typically for source selection, power states, scene recall, or device switching. The buttons include backlit feedback showing on/off and flash states.
How does it connect to my network and other devices?
The pad connects via 10/100 Ethernet with Auto MDI/MDI-X (works with straight or crossover cables) and supports Power over Ethernet, so no separate power supply is needed. It also includes Serial and IR ports to integrate with legacy devices like projectors, lighting systems, or older AV gear.
Does this work for live sound or recording?
No—this control pad is designed for permanent AV system integration, building automation, and conference rooms. It is not suitable for live performance sound reinforcement or home/studio recording applications.
What are the mounting dimensions and wall compatibility?
The pad measures 3 7/16" × 4 11/16" × 9/16" and mounts directly into standard single-gang US, UK, or EU electrical back boxes. The landscape orientation is optimized for button accessibility in professional control room and permanent installation settings.
What makes this different from home automation keypads?
The MCP-106L-WH includes an onboard NX-series controller with professional networking and security architecture, Serial and IR ports for legacy device integration, and is built for integrated AV and building automation in commercial and professional environments. It is not a consumer home-automation device.
