AMX MCP-106P-WH Massio™ 6-Button ControlPad - White - Portrait
Description
AMX MCP-106P-WH Massio™ 6-Button ControlPad - White - Portrait
The MCP-106P-WH is a compact wall-mounted control interface built for live venues, installed systems, and sound reinforcement environments. Its portrait orientation and streamlined 6-button layout put essential commands within arm's reach in tight FOH positions and stage-side locations, while the backlit button design cuts through dark rooms and maintains visibility even in variable lighting conditions.
Control & Connectivity
This control pad communicates via 10/100 Ethernet with auto MDI/MDI-X capability, letting you run either straight-through or crossover cables without worrying about cable type compatibility. Native PoE (Power over Ethernet) support means one cable handles both signal and power—no separate supplies to manage or troubleshoot during setup. Integrated serial and IR ports expand your integration options, bridging older gear with current-generation devices and keeping legacy equipment in your control chain.
Design & Installation
Built for straightforward mounting, the MCP-106P-WH fits directly into standard 1-gang US, UK, or EU back boxes, keeping your wall installations neat and code-compliant. The compact portrait footprint and white finish blend into any venue—residential, commercial, or temporary install—without calling attention to itself or getting in the way.
Key Features
- 6 customizable buttons with programmable functionality
- Backlit buttons with selectable flash or on/off modes
- 10/100 Ethernet port with TCP/IP communication
- Auto MDI/MDI-X enabled for flexible cable deployment
- Power over Ethernet (PoE) capable
- Integrated serial and IR ports for expanded device control
- Macro support for executing multiple functions with single button press
- Standard 1-gang US, UK, and EU back box compatible
- Portrait orientation: 4 11/16" × 3 7/16" × 9/16" (119 mm × 87.5 mm × 13.9 mm)
- White finish
The MCP-106P-WH delivers rock-solid network-native control for distributed AV and automation systems without requiring dedicated power runs or extra infrastructure on site.
More Information
| Condition | New |
|---|
Reviews
At a Glance
The AMX MCP-106P-WH is a compact, wall-mounted 6-button control pad that integrates into standard electrical boxes for managing AV systems and venue automation. Built for live-sound and stage environments, it communicates over Ethernet with Power-over-Ethernet support, eliminating extra power runs to the wall. Its backlit buttons, macro capability, and network-native design make it reliable for touring and permanent installations where clean cable management and intuitive control matter.
Frequently Asked Questions
What does PoE (Power over Ethernet) mean for my installation?
PoE allows the control pad to receive both data and power from a single Ethernet cable, eliminating the need for a separate power supply and reducing wiring complexity in walls or behind equipment racks.
Can I use this with older AV equipment or only modern devices?
The MCP-106P-WH includes integrated serial and IR ports in addition to Ethernet, so it can control both legacy devices and contemporary networked systems.
What does 'macro support' do?
Macros let you program a single button to execute multiple functions or commands in sequence, reducing the number of button presses needed to perform complex operations.
Will this fit into my existing wall outlet box?
Yes—the MCP-106P-WH is engineered for standard 1-gang US, UK, and EU electrical back boxes, so it mounts directly into existing infrastructure without special framing or modifications.
Do the buttons stay lit all the time, or can I control when they light up?
The backlit buttons are programmable with selectable flash or on/off modes, giving you full control over visual feedback in any lighting condition.
