AMX MET-13E-WH Metreau Keypad 13-button WHITE

AMX MET-13E-WH Metreau 13-Button White Keypad

The AMX MET-13E-WH is a compact networked control keypad built for live venues, studios, and touring installations where reliable system control matters. Its clean white faceplate and tactile 13-button layout deliver straightforward access to critical AV and sound system functions, with LED indicators providing clear visual feedback in any stage or venue lighting condition.

Control Layout & Operation

This keypad features 13 buttons—twelve single-width and one double-width—letting you map commands for lighting, video, mixing feeds, or other system functions with immediate tactile response. LED illumination on each button confirms status and active controls at a glance, essential when you're managing a live event and can't afford confusion.

Integration & Connectivity

The MET-13E-WH connects via RJ-45 Ethernet (10/100) and draws power directly from the network through 802.3af PoE, cutting down on wall-wart clutter and power cable runs. Two rear-panel 8-pin IDC-type header connectors provide hardwired control backup options, and the unit mounts into standard Decora-style wall plates for quick installation in any venue or temporary setup.

Key Features

• 13-button configuration (12 single-width, 1 double-width)
• LED backlighting for visual feedback
• RJ-45 Ethernet connectivity, 10/100
• Power over Ethernet (PoE) 802.3af, class 0
• Two 8-pin, 0.100" IDC-type male header connectors on rear panel
• Mounts into standard Decora-style wall plates
• Compact dimensions: 4" H × 1¾" W × 1" D
• Operating temperature range: 32°F to 104°F (0°C to 40°C)
• Operating humidity: 5% to 85%, non-condensing
• White finish (MET-13E-WH)

The MET-13E-WH delivers dependable networked control in a form factor that integrates naturally into live sound, AV, and venue installations where uptime and reliability are non-negotiable.
