AMX MET-13E-WH Metreau Keypad 13-button WHITE
- Brand new in original box
- Full AMX manufacturer's warranty
- Free shipping in the continental US
In stock
- SKU
- FG5793-02-WH
Description
AMX MET-13E-WH Metreau 13-Button White Keypad
The AMX MET-13E-WH is a compact networked control keypad built for live venues, studios, and touring installations where reliable system control matters. Its clean white faceplate and tactile 13-button layout deliver straightforward access to critical AV and sound system functions, with LED indicators providing clear visual feedback in any stage or venue lighting condition.
Control Layout & Operation
This keypad features 13 buttons—twelve single-width and one double-width—letting you map commands for lighting, video, mixing feeds, or other system functions with immediate tactile response. LED illumination on each button confirms status and active controls at a glance, essential when you're managing a live event and can't afford confusion.
Integration & Connectivity
The MET-13E-WH connects via RJ-45 Ethernet (10/100) and draws power directly from the network through 802.3af PoE, cutting down on wall-wart clutter and power cable runs. Two rear-panel 8-pin IDC-type header connectors provide hardwired control backup options, and the unit mounts into standard Decora-style wall plates for quick installation in any venue or temporary setup.
Key Features
- 13-button configuration (12 single-width, 1 double-width)
- LED backlighting for visual feedback
- RJ-45 Ethernet connectivity, 10/100
- Power over Ethernet (PoE) 802.3af, class 0
- Two 8-pin, 0.100" IDC-type male header connectors on rear panel
- Mounts into standard Decora-style wall plates
- Compact dimensions: 4" H × 1¾" W × 1" D
- Operating temperature range: 32°F to 104°F (0°C to 40°C)
- Operating humidity: 5% to 85%, non-condensing
- White finish (MET-13E-WH)
The MET-13E-WH delivers dependable networked control in a form factor that integrates naturally into live sound, AV, and venue installations where uptime and reliability are non-negotiable.
More Information
| Condition | New |
|---|---|
| Country of Manufacture | Mexico |
Reviews
At a Glance
The AMX MET-13E-WH is a 13-button networked control keypad designed for professional AV and building automation systems—not for live sound or musical performance. It connects via Ethernet with Power over Ethernet (PoE), mounts into standard wall plates, and offers LED-backlit buttons for clear feedback in any lighting. Choose this if you're setting up conference rooms, installed AV systems, or building automation that demands reliable networked control.
Who This Is For
| Best suited for | AV system control, building automation, conference room setup, installation |
|---|---|
| Less specialized for | musical performance, audio mixing, live sound (it will do it; instruments voiced for that style do it more easily) |
| Skill level | Professional |
Frequently Asked Questions
What exactly does this keypad control?
The MET-13E-WH is a networked control interface that can be mapped to various AV and building automation functions within a larger system—lighting, displays, climate, cameras, or other installed equipment. It connects to a control system via Ethernet and does not perform audio mixing or live sound control.
What are the power and connectivity requirements?
The keypad draws power directly from the network through 802.3af Power over Ethernet (PoE), eliminating the need for a separate power supply. It connects via RJ-45 Ethernet (10/100) and also includes two 8-pin rear-panel connectors for wired control integration.
Will it fit into my existing wall installation?
Yes—the MET-13E-WH mounts into standard Decora-style wall plates and measures 4 inches high by 1¾ inches wide by 1 inch deep, making it suitable for professional installation in conference rooms and commercial AV environments.
What kind of visual feedback does it provide?
Each of the 13 buttons (12 single-width and 1 double-width) features LED backlighting that illuminates to show active controls and status, providing clear feedback in any lighting condition.
Do I pay sales tax on this order?
Sales tax is collected only on orders shipped to California; orders shipped to any other US state are not charged sales tax at checkout when you buy direct from our website. At a typical 7% rate that is an estimated $34 less at checkout than the same listed price on a marketplace, which collects sales tax as the facilitator in most states. Buyers remain responsible for any use tax their state applies. Free US shipping and 30-day returns are included.
