Cinema CRF2
- Brand new in original box
- Full Cinema manufacturer's warranty
- Free shipping in the continental US
In stock
- SKU
- CRF2
Description
JBL Cinema CRF2 Reflector Horn for Cinema Loudspeakers
The Cinema CRF2 is a professional-grade reflector horn designed for cinema sound installations where precise mid-range and high-frequency reproduction is critical. This pair of horns employs patented Dual Dissimilar Array technology and a 30-degree flush-mount design to deliver controlled directivity and seamless integration into cinema environments. Built for installations requiring robust, cinema-grade audio performance, the CRF2 represents serious pro-audio engineering.
Audio Performance & Coverage
The CRF2 achieves a sensitivity rating of 102 dB at 2.83V @ 1m, delivering substantial output from moderate amplifier input. The frequency response spans 2.33kHz–11.2kHz at 3dB, with extended response to 23kHz at -10dB, making these horns ideal for cinema mid-range and treble reproduction. The dual 2415J-XP 37.5mm (1.5 in) compression drivers work in tandem to ensure smooth, controlled coverage across the cinema frequency range.
Installation & Specifications
Rated for 150 Watts AES (100 hours) with a recommended amplifier of 300 Watts, the CRF2 offers headroom for consistent, clean operation in demanding installations. The 8Ω impedance rating (minimum 6.65Ω @ 20kHz) integrates easily into cinema loudspeaker systems. Compact dimensions of 508 × 439 × 368mm (20 × 17.3 × 14.5 in) and a weight of 11.3kg (25 lb) per unit keep the horns manageable, while the 2520 mounting bracket (sold separately) ensures secure, angled installation.
Key Features
- Two 2415J-XP 37.5mm (1.5 in) compression drivers per unit
- Rated impedance: 8Ω (minimum 6.65Ω @ 20kHz)
- Frequency response (3dB): 2.33kHz–11.2kHz
- Frequency response (-10dB): 2.09kHz–23kHz
- Input power rating: 150 Watts AES (100 hours); 300 Watts recommended amplifier
- Sensitivity: 102 dB at 2.83V @ 1m
- Dimensions: 508 × 439 × 368mm (20 × 17.3 × 14.5 in)
- Net weight: 11.3kg (25 lb) each
- 30-degree angle horn design for flush mounting
- Patented Dual Dissimilar Array technology
- Requires 2520 mounting bracket (sold separately)
- Sold as a left/right pair
The CRF2 pair delivers cinema-grade mid and high-frequency reproduction with the engineering precision and power handling cinema installations demand.
More Information
| Condition | New |
|---|
Reviews
At a Glance
The Cinema CRF2 is a professional reflector horn pair built for cinema and high-end theater installations where precise mid and high-frequency reproduction cannot be compromised. Engineered with dual compression drivers and patented Dual Dissimilar Array technology, these horns deliver controlled directivity and cinema-grade clarity across the critical midrange and treble—ideal for commercial AV systems and installations where acoustic precision is non-negotiable. Choose the CRF2 for robust, dependable performance in demanding fixed installations where seamless integration and extended frequency response are essential.
Who This Is For
Great for
- ✓ Cinema installations
- ✓ High-end theater sound
- ✓ Commercial AV systems
- ✓ Studio monitoring
Not the best pick for
- – Portable PA
- – Small venue live sound
- – Home audio
Skill level: Professional
Frequently Asked Questions
What is the frequency response of the CRF2?
The CRF2 covers 2.33kHz–11.2kHz at 3dB, with extended response reaching 23kHz at -10dB. This range prioritizes cinema-grade mid and treble reproduction for professional installations.
What amplifier power do I need for the CRF2?
The CRF2 is rated for 150 Watts AES (100 hours), with a recommended amplifier of 300 Watts to ensure headroom and clean operation in demanding installations. The impedance is 8Ω (minimum 6.65Ω @ 20kHz).
How are the CRF2 horns mounted?
The CRF2 features a 30-degree flush-mount design and requires the 2520 mounting bracket (sold separately) for secure, angled installation. Compact dimensions of 508 × 439 × 368mm (20 × 17.3 × 14.5 in) per unit keep the horns manageable in cinema environments.
What's included in the CRF2 pair?
You receive a left/right pair of reflector horns, each with dual 2415J-XP 37.5mm compression drivers. The 2520 mounting bracket is sold separately and required for installation.
What sets the CRF2 apart from other cinema horns?
The CRF2 employs patented Dual Dissimilar Array technology and achieves 102 dB sensitivity at 2.83V @ 1m, delivering controlled directivity and seamless cinema integration. This engineering is optimized for professional installations where mid and high-frequency precision is critical.
