JBL AC115S-WH 15" Subwoofer, white
Description
JBL AC115S-WH 15" Subwoofer, White
The AC115S-WH is a compact powered subwoofer engineered to anchor the low end of your live sound rig without consuming your truck bed. Its front-loaded vented design and modest footprint work equally well in installed venues, portable PA setups, and fixed installations where controlled bass is essential. The white finish integrates seamlessly into white interior environments.
Output & Performance
This unit delivers 120 dB SPL maximum output (126 dB peak) at 1 meter—muscle enough for medium-sized rooms and outdoor applications. The 400 W continuous power rating (800 W program, 1600 W peak) maintains clean, stable bass reproduction across the frequency range without distortion, and 94 dB system sensitivity means it responds dependably to moderate input levels without requiring extreme gain settings.
Design & Build
The enclosure uses 18 mm multi-ply hardwood plywood with a durable textured white paint finish that holds up under road use. The grille features powder-coated 1.5 mm perforated steel backed by acoustically transparent foam for protection. Connectivity comprises dual Neutrik NL4MP connectors plus covered barrier trip terminals, giving you wiring options for different rig configurations, and 12 M10 threaded suspension points support rigging for stage deployment or fixed installation.
Key Features
- 15-inch low-frequency driver, 3-inch voice coil, vented front-loaded configuration
- Frequency range: 32–250 Hz (−10 dB); 40–250 Hz (±3 dB)
- 400 W continuous / 800 W program / 1600 W peak power rating (IEC)
- Maximum SPL: 120 dB (126 dB peak) @ 1 meter
- System sensitivity: 94 dB (1W @ 1m)
- Nominal impedance: 8 ohms
- Dual Neutrik NL4MP connectors plus covered barrier trip terminals
- 18 mm multi-ply hardwood plywood enclosure with white textured finish
- Powder-coated perforated steel grille with acoustically transparent foam backing
- 12 M10 threaded suspension points for rigging and mounting
- Dimensions: 19 × 16.5 × 23.6 inches (483 × 419 × 600 mm)
- Weight: 24 kg (52.9 lbs)
The AC115S-WH combines reliable low-end extension, pro-grade connectivity, and rigging flexibility in a road-ready package built for touring and venue installations.
More Information
| Condition | New |
|---|
Reviews
At a Glance
The JBL AC115S-WH is a compact 15-inch powered subwoofer delivering 120 dB SPL maximum output with tight, controlled bass extension down to 32 Hz, built for live sound reinforcement and portable PA rigs where space and reliability matter. Its vented front-loaded design, dual Neutrik connectors, and 12 rigging points make it road-ready for gigging musicians and sound engineers running medium-sized venues and outdoor events. Choose it for undistorted low-end punch that won't eat up floor real estate or overpower a mix.
Who This Is For
Great for
- ✓ Live Performance
- ✓ Studio Sessions
- ✓ Gigging
- ✓ Installed Sound Systems
Not the best pick for
- – Home Practice
- – Bedroom Recording
Skill level: Intermediate · Advanced · Professional
Frequently Asked Questions
What size room or venue is this subwoofer designed for?
The AC115S-WH is rated for medium-sized rooms and outdoor applications, producing 120 dB SPL maximum output at 1 meter. It's sized for installed sound systems and portable PA rigs where you need reinforcement without a large footprint.
How low does this subwoofer go, and what's the frequency range?
The AC115S-WH reaches down to 32 Hz at −10 dB and 40 Hz at ±3 dB, with an operational range of 40–250 Hz. This deep low-end extension works well for bass guitar, kick drum, and general low-frequency reinforcement.
What are the connectivity and rigging options?
It includes dual Neutrik NL4MP connectors plus covered barrier trip terminals for flexible wiring, and 12 M10 threaded suspension points support both floor placement and rigging for installed or hanging applications.
How much power does it have, and will it distort under load?
The unit delivers 400 W continuous / 800 W program / 1600 W peak power (IEC), with 94 dB system sensitivity ensuring stable, undistorted bass reproduction even at modest input levels.
What's the physical size and weight, and does the white finish integrate well?
Dimensions are 19 × 16.5 × 23.6 inches with a weight of 52.9 lbs, making it portable for gigging or installed systems. The durable textured white finish blends cleanly into white interior environments and venues.
