JBL AM5212/00-WH Two-way full range loudspeaker (white)
Description
JBL AM5212/00-WH Two-Way Full Range Loudspeaker (White)
The AM5212/00-WH is a professional-grade loudspeaker engineered for consistent, controlled coverage in mid-sized venues and installations. Its trapezoid enclosure and rotatable waveguide offer flexible deployment options, while the combination of a 12-inch woofer and compression driver delivers balanced output across the full frequency spectrum with minimal coloration.
Sonic Performance & Coverage
This speaker reproduces audio from 43 Hz to 20 kHz, capturing the full range of musical and speech content with clarity and extension. The PT Progressive Transition waveguide maintains tight 100° × 100° coverage throughout the frequency range, ensuring even sound distribution without dead zones or hot spots in the listening area.
Design & Construction
Built from multiply birch with DuraFlex finish, the enclosure resists warping and environmental stress while maintaining a professional appearance across touring seasons and permanent installations. The rotatable waveguide allows deployment in either vertical or horizontal orientation, and M10 threaded attachment points accommodate permanent or semi-permanent rigging solutions. A 14-gauge steel grille protects the drivers while remaining acoustically transparent.
Key Features
- 262H-1 Differential Drive low-frequency driver (300 mm / 12 inch)
- 2408H-1 high-frequency compression driver (38 mm / 1.5 inch exit and voice-coil)
- Frequency response: 43 Hz–20 kHz
- 100° × 100° coverage via PT Progressive Transition waveguide
- Rotatable waveguide for vertical or horizontal orientation
- Multiply birch enclosure with DuraFlex finish
- Trapezoid design with M10 threaded attachment points
- NL4 Neutrik Speakon and covered barrier strip terminals
- Switchable bi-amp and passive operation modes
- Barrier terminals accept up to 5.2 sq mm (10 AWG) wire or 9 mm spade lugs
- Mil-Std 810 environmental specifications
- IP-x3 rated per IEC529
The AM5212/00-WH combines durable construction with professional-level acoustic performance, making it a trusted choice for permanent installations, touring systems, and venues requiring predictable coverage and extended frequency response.
More Information
| Condition | New |
|---|
Reviews
At a Glance
The JBL AM5212/00-WH is a professional two-way loudspeaker built for touring, live venues, and installations where consistent coverage and reliability matter. Its 12-inch woofer and compression driver deliver balanced full-range sound from 43 Hz to 20 kHz with tight, predictable coverage and minimal coloration, while the birch enclosure and rotatable waveguide handle road wear and flexible stage placement. Choose this speaker when you need road-tested durability, even sound distribution across mid-sized rooms, and the confidence that your tone stays clean and present no matter where the gig takes you.
Who This Is For
Great for
- ✓ Live Performance
- ✓ Touring
- ✓ Studio Sessions
- ✓ Worship
Not the best pick for
- – Home Recording
- – Practice
Skill level: Professional
Frequently Asked Questions
What size venues and rooms is this speaker designed for?
The AM5212/00-WH is engineered for mid-sized venues and installations. Its 100° × 100° coverage from the PT Progressive Transition waveguide ensures even sound distribution without dead zones, making it ideal for touring rigs, clubs, theaters, and permanent installations where predictable coverage across a defined area is required.
Can I mount this speaker in different orientations?
Yes. The rotatable waveguide allows deployment in either vertical or horizontal orientation, and M10 threaded attachment points accommodate permanent rigging, semi-permanent stands, or floor placement depending on your venue or installation layout.
What kind of amplification and wiring does it require?
The AM5212/00-WH supports both passive and bi-amp operation modes, so you can run it from a single powered channel or split the low and high frequencies to separate amps for more control. Barrier terminals accept up to 10 AWG wire or 9 mm spade lugs, and an NL4 Neutrik Speakon connector is also provided.
How durable is this speaker for touring and outdoor use?
The enclosure is built from multiply birch with DuraFlex finish to resist warping and environmental stress. The speaker meets Mil-Std 810 environmental specifications and is IP-x3 rated per IEC 529, making it reliable for touring, semi-permanent venues, and installations exposed to variable conditions.
What drivers does this speaker use?
The AM5212/00-WH combines a 262H-1 Differential Drive 12-inch woofer (300 mm) and a 2408H-1 high-frequency compression driver (38 mm exit and voice-coil). A 14-gauge steel grille protects both drivers while remaining acoustically transparent.
