JBL AM5212/64-WH Two-way full range loudspeaker (white)
Share
- Brand new in original box
- Full JBL manufacturer's warranty
- Free shipping in the continental US
In stock
- SKU
- AM5212-64-WH
Description
JBL AM5212/64-WH Two-Way Full Range Loudspeaker
The AM5212/64-WH is a medium-power, lightweight two-way system engineered for venues and installations requiring reliable full-range coverage without excessive bulk. Its trapezoid enclosure and rotatable waveguide design adapt to both vertical and horizontal mounting, making it a practical choice for permanent installs, portable rentals, and systems where space efficiency matters. The white finish integrates cleanly into corporate, hospitality, and commercial environments.
Audio Performance
This speaker delivers consistent coverage across a 60° × 40° dispersion pattern with a frequency response of 43 Hz–18 kHz, covering the full audible spectrum for speech, music, and general purpose reinforcement. The pairing of a 300 mm low-frequency driver with a compression driver and large-format PT™ Progressive Transition waveguide ensures smooth tonal integration and minimal phase anomalies across the crossover region.
Reliability & Rigging
Heavy bracing and multiply birch construction with DuraFlex finish create a rigid, durable enclosure that resists flexing and unwanted resonance. The fifteen M10 threaded attachment points provide flexible rigging and mounting options, while the switchable bi-amp and passive modes accommodate various amplifier configurations and system architectures—essential for touring and multi-system setups.
Key Features
- 262H-1 300 mm (12 in) Differential Drive low-frequency driver with dual voice coil and dual magnetic gap
- 2408H-1 high-frequency compression driver with 38 mm (1.5 in) exit and 38 mm (1.5 in) voice coil
- Frequency response: 43 Hz–18 kHz
- Coverage pattern: 60° × 40°
- Medium power, lightweight two-way full-range system
- Large format PT™ Progressive Transition waveguide
- Rotatable waveguide for vertical or horizontal orientation
- Multiply birch enclosure with DuraFlex finish and heavy bracing
- Trapezoid enclosure design with fifteen M10 threaded attachment points
- High-slope passive networks minimize band overlap
- Switchable bi-amp and passive modes
- NL4 speakON and Barrier Strip connectivity options
The AM5212/64-WH combines proven JBL engineering with practical installation flexibility, making it a dependable choice for fixed venues, temporary systems, and applications where consistent, articulate coverage is required.
More Information
| Condition | New |
|---|
Reviews
At a Glance
The JBL AM5212/64-WH is a medium-power two-way full-range speaker built for live venues, corporate events, and hospitality spaces where reliable coverage and clean aesthetics matter. Its rotatable waveguide and trapezoid enclosure adapt to vertical or horizontal mounting in fixed installs or portable setups, while the articulate midrange and smooth crossover integration deliver consistent, phase-coherent sound across 43 Hz–18 kHz. Choose this speaker for dependable stage and venue reinforcement with road-ready durability and flexible rigging options that handle diverse sound-system architectures.
Who This Is For
Great for
- ✓ Live Performance
- ✓ Gigging
- ✓ Corporate Events
- ✓ Hospitality Venues
Not the best pick for
- – Home Recording
- – Practice
Skill level: Intermediate · Advanced · Professional
Frequently Asked Questions
What mounting and rigging options does the AM5212/64-WH offer?
The speaker features fifteen M10 threaded attachment points and a rotatable waveguide that adapts to both vertical and horizontal orientation, supporting flexible rigging, pole-mounting, and wall or bracket installation. It includes NL4 speakON and Barrier Strip connectivity for various amplifier configurations.
What is the coverage pattern and frequency response?
The AM5212/64-WH delivers a 60° × 40° consistent coverage pattern with a frequency response of 43 Hz–18 kHz, covering the full audible spectrum for speech, music, and general-purpose reinforcement in mid-sized venues and installations.
Can I use the AM5212/64-WH in both passive and bi-amp configurations?
Yes, the speaker is switchable between passive and bi-amp modes, allowing it to integrate into various system architectures and amplifier setups without requiring modification.
What drivers and waveguide design does this speaker use?
The AM5212/64-WH pairs a 300 mm Differential Drive low-frequency driver with dual voice coil and dual magnetic gap with a 2408H-1 high-frequency compression driver and a large-format PT Progressive Transition waveguide, ensuring smooth crossover integration and minimal phase anomalies.
Is the white finish durable for commercial and hospitality environments?
The multiply birch enclosure is finished with a DuraFlex coating and heavy internal bracing to resist flexing and unwanted resonance, making it durable for fixed venues, hospitality spaces, and corporate installations where clean aesthetics are required.
