JBL AM5215/64-WH Two-way full range loudspeaker (white)
Description
JBL AM5215/64-WH Two-way Full Range Loudspeaker (White)
The AM5215/64-WH is a professional full-range loudspeaker engineered for live sound reinforcement in medium-format venues, houses of worship, and installed applications. Its compact yet robust cabinet delivers articulate coverage across a wide frequency spectrum, with the flexibility to orient the horn vertically or horizontally depending on your stage setup or permanent installation requirements.
Audio Performance
Frequency response extends from 41 Hz to 18 kHz, providing full-spectrum coverage from deep bass through crisp highs. The dual-component driver design pairs a 380 mm (15 in) low frequency driver with differential drive technology alongside a 38 mm (1.5 in) exit/voice-coil compression driver, achieving 98 dB SPL sensitivity (1W @ 1m) for efficient operation in both passive and bi-amped configurations—essential for tour-ready systems and permanent installations that demand consistent output.
Design & Build
The cabinet is constructed from heavily braced multi-ply birch finished in JBL's DuraFlex coating for durability in demanding environments and on the road. A 14-gauge steel grille with internally lined acoustically transparent foam protects the drivers while maintaining sonic transparency, secured by fifteen M10 threaded attachment points for reliable, tool-free installation and confident stacking during load-in and load-out.
Key Features
- 380 mm (15 in) JBL Differential Drive low frequency driver with dual voice coil and dual magnetic gap
- 38 mm (1.5 in) exit/voice-coil compression driver (2408H-1) for precise mid and high frequency reproduction
- 60 x 40° coverage pattern for controlled directional projection
- Frequency response: 41 Hz to 18 kHz
- 98 dB SPL sensitivity (1W @ 1m) in passive mode
- Bi-amped or passive switchable operation for flexible system configuration
- NL4 Neutrik speakON connectors and CE-compliant covered barrier strip terminals
- Rotatable horn deployable in vertical or horizontal orientation
- Multi-ply birch cabinet with DuraFlex finish
- Heavily braced construction for cabinet rigidity and reduced resonance
- 14-gauge steel grille with integrated acoustically transparent foam lining
- Fifteen M10 threaded attachment points for secure mounting and stacking
The AM5215/64-WH combines JBL's professional driver technology with field-proven construction to deliver reliable, articulate sound reinforcement across live venues, touring applications, and permanent installations.
More Information
| Condition | New |
|---|
Reviews
At a Glance
The JBL AM5215/64-WH is a professional two-way full-range loudspeaker built for live venues, houses of worship, and installed sound systems where reliable, articulate coverage matters. Its 15-inch woofer and compression driver deliver 98 dB sensitivity with controlled 60×40° directivity, meaning your sound carries clearly and stays focused without muddiness or feedback trouble. Heavily braced birch construction, tool-free M10 mounting, and switchable passive/bi-amped operation make it a dependable workhorse for touring, fixed installations, or any gig where you need pro-grade projection you can count on night after night.
Who This Is For
Great for
- ✓ Live Performance
- ✓ House of Worship
- ✓ Installed Sound
- ✓ Studio Monitoring
Not the best pick for
- – Home Practice
- – Bedroom Recording
Skill level: Intermediate · Advanced · Professional
Frequently Asked Questions
What's the frequency response and sensitivity?
The AM5215/64-WH covers 41 Hz to 18 kHz and delivers 98 dB SPL at 1 watt at 1 meter, making it efficient enough to run passively or bi-amped depending on your system design.
Can I mount this in different orientations?
Yes—the 60×40° horn rotates between vertical and horizontal mounting, and the cabinet features fifteen M10 threaded attachment points for flexible installation and secure stacking.
What's included for connectivity?
The speaker comes with NL4 Neutrik speakON connectors and CE-compliant covered barrier strip terminals, allowing both professional audio XLR-style connections and traditional barrier-strip wiring.
Is this speaker suitable for studio monitoring or mainly live sound?
While it's designed primarily for live venues, houses of worship, and installed sound, its articulate full-spectrum response and controlled directivity make it suitable for studio reinforcement and reference monitoring in treated acoustic spaces.
What's the cabinet construction like?
The AM5215/64-WH uses heavily braced multi-ply birch with JBL's DuraFlex finish and a 14-gauge steel grille with acoustically transparent foam lining, delivering durability and rigidity for demanding touring and installation environments.
