JBL AM7212/00 S/m, AM7212/00
Description
JBL AM7212/00 S/m 12" Two-Way Passive/Bi-Amp Speaker System
The JBL AM7212/00 is a road-ready mid-size loudspeaker built for reliable, controlled coverage in live sound and installed applications. Its compact footprint and flexible mounting options make it equally effective as a main speaker, fill unit, or stage monitor, delivering professional output without demanding excessive amplifier resources or complex rigging setup.
Audio Performance & Coverage
This system combines a 12-inch low-frequency driver with a 1.5-inch compression driver on a rotatable waveguide, covering a 100° × 100° pattern that maintains coherent sound across its listening area. Peak output reaches 132 dB-SPL (LF) and 137 dB-SPL (HF) in bi-amp mode, with 95 dB SPL sensitivity in passive mode, making it capable of significant reinforcement in mid-sized venues without excessive amplifier demand.
Design & Build Quality
The enclosure is constructed from braced multi-ply birch with JBL's DuraFlex finish, wrapped in a 14-gauge perforated steel grille lined with acoustically transparent foam built to withstand touring and venue environments. The speaker features 15 M10 threaded suspension points and a rotatable waveguide for vertical or horizontal orientation, allowing quick reconfiguration on the fly for different stage and room layouts.
Key Features
- Frequency response ±3 dB: 42 Hz – 20 kHz
- Frequency range (-10 dB): 36 Hz – 20 kHz
- Coverage pattern: 100° × 100° with directivity index of 9.1 dB
- 2262H 300mm (12 in) low-frequency driver
- 2432H high-frequency compression driver, 38 mm exit / 75 mm voice-coil
- Passive crossover at 1.5 kHz with bi-amp/passive switchable modes
- Long-term power rating (IEC passive): 600 W continuous (2400 W peak) for 100 hours
- Low-frequency transducer: 1000 W AES (4000 W peak, 2 hrs); 700 W (2800 W peak, 100 hrs)
- High-frequency transducer: 100 W AES (400 W peak, 2 hrs)
- Nominal impedance: 8 Ohms
- 15 M10 threaded suspension points with rotatable waveguide
- Multi-ply birch enclosure with DuraFlex finish and heavy bracing
The AM7212/00 delivers accurate, controlled sound reinforcement through a balanced design that prioritizes reliability, coverage consistency, and straightforward deployment in both temporary and permanent installations.
More Information
| Condition | New |
|---|
Reviews
At a Glance
The JBL AM7212/00 is a compact 12-inch two-way passive/bi-amp speaker built for mid-sized venues, tours, and permanent installations where consistent coverage and durability matter. Designed for intermediate to professional sound operators, it delivers 132–137 dB SPL output with balanced midrange articulation and controlled low-end, making it reliable as a main, fill, or monitor unit without heavy rigging demands. Its braced birch cabinet, rotatable waveguide, and 15 suspension points handle the road and install environments where versatility and uptime are non-negotiable.
Who This Is For
Great for
- ✓ Live Performance
- ✓ Installed Sound
- ✓ Touring
- ✓ Stage Monitoring
Not the best pick for
- – Home Recording
- – Studio Sessions
Skill level: Intermediate · Advanced · Professional
Frequently Asked Questions
What is the AM7212/00 best suited for?
The AM7212/00 excels in live-sound reinforcement, touring, installed sound systems, and stage monitoring. Its 100° × 100° coverage pattern and 132–137 dB SPL output make it ideal for mid-sized venues where consistent, reliable coverage across the listening area is critical. It is not designed for studio recording or mixing.
Can this speaker work in passive or bi-amp mode?
Yes. The AM7212/00 includes a passive crossover at 1.5 kHz and can operate in either passive mode (95 dB SPL sensitivity, 600 W continuous rating) or bi-amp mode (132–137 dB SPL peak output), giving you flexibility to match your amplifier setup and venue demands.
How much space does it take up, and can I mount it different ways?
The AM7212/00 features a compact footprint with 15 M10 threaded suspension points and a rotatable waveguide, allowing vertical or horizontal mounting and flexible rigging in tight spaces. Its braced multi-ply birch construction and steel grille handle touring and permanent installations without damage.
What frequency range does it cover?
The AM7212/00 covers 42 Hz – 20 kHz at ±3 dB and extends to 36 Hz – 20 kHz at -10 dB, delivering balanced midrange articulation with controlled low-end and articulate highs suitable for full-range reinforcement in live and installed sound applications.
Is this speaker durable for touring and outdoor use?
Yes. The cabinet is constructed from braced multi-ply birch with JBL's DuraFlex finish and wrapped in a 14-gauge perforated steel grille lined with acoustically transparent foam, designed to withstand the rigors of touring and installed environments.
