JBL AM7212/26-WH Two-way full range loudspeaker (white)
Description
JBL AM7212/26-WH Two-Way Full Range Loudspeaker
The AM7212/26-WH is a workhorse two-way system built for the people running sound at mid-size venues, installed systems, and touring rigs. Its rotatable waveguide and multi-ply birch construction deliver consistent coverage and real-world durability in whatever environment you're operating in, while the compact footprint and 51 lb weight make it straightforward to position and integrate into your install—no fighting with gear that won't cooperate.
Driver Configuration & Coverage
This system pairs a 2262H 12-inch low frequency driver with dual voice coil and dual magnetic gap architecture against a 2432H high frequency compression driver featuring a 1.5-inch exit and 3-inch voice coil. The large-format Progressive Transition waveguide delivers 120 × 60° coverage, ensuring smooth directional control and consistent sound across the listening plane without phase cancellation or hot spots—your coverage stays predictable night to night.
Construction & Reliability
Heavy internal bracing and multi-ply birch enclosure with DuraFlex finish stand up to road wear, venue loading, and environmental stress without breaking down. The rotatable waveguide handles both vertical and horizontal mounting, while fifteen M10 threaded attachment points give you the rigging and structural integration options you need; the 14-gauge steel grille with acoustically transparent foam lining protects the drivers without altering the sound.
Key Features
- 2262H 12-inch low frequency driver with dual voice coil and dual magnetic gap
- 2432H high frequency compression driver with 1.5-inch exit and 3-inch voice coil
- Large-format Progressive Transition waveguide with 120 × 60° coverage pattern
- Rotatable waveguide for vertical or horizontal orientation
- Multi-ply birch enclosure with DuraFlex finish, heavily internally braced
- 14-gauge steel grille with acoustically transparent foam lining
- Bi-Amp/Passive switchable configuration
- High-slope passive networks minimize band overlap
- Fifteen M10 threaded attachment points for rigging and installation
- Weight: 51 lbs (23.1 kg)
The AM7212/26 combines proven driver technology with flexible mounting and field-tested durability, making it a dependable choice for both temporary and permanent sound systems.
More Information
| Condition | New |
|---|
Reviews
At a Glance
The JBL AM7212/26-WH is a professional two-way loudspeaker built for mid-size venues, touring, and installed sound systems, delivering 120 × 60° coverage with minimal phase cancellation and consistent directional control. Its rotatable waveguide, 51 lb weight, and multi-ply birch construction make it road-ready and easy to position for both temporary and permanent setups. Choose it for reliable full-range response and proven durability in demanding live environments.
Who This Is For
Great for
- ✓ Live Performance
- ✓ Touring
- ✓ Installed Sound Systems
Not the best pick for
- – Home Recording
- – Practice
Skill level: Professional
Frequently Asked Questions
What is the coverage pattern and directional control of this speaker?
The AM7212/26-WH features a 120 × 60° coverage pattern delivered by the large-format Progressive Transition waveguide, ensuring smooth directional control and consistent sound across the listening plane without phase cancellation or hot spots.
Can this speaker be mounted vertically or horizontally?
Yes, the rotatable waveguide allows both vertical and horizontal mounting orientations, and the speaker includes fifteen M10 threaded attachment points for rigging hardware and structural integration in various installation scenarios.
What drivers and configuration does it use?
It pairs a 2262H 12-inch low frequency driver with dual voice coil and dual magnetic gap against a 2432H high frequency compression driver with a 1.5-inch exit and 3-inch voice coil, with bi-amp/passive switchable configuration.
How durable is this speaker for touring and installed use?
The multi-ply birch enclosure with DuraFlex finish and heavy internal bracing provide rigidity and protection against road wear and environmental conditions; the 14-gauge steel grille with acoustically transparent foam lining protects drivers without coloration.
What is the weight and is it practical for positioning?
The speaker weighs 51 lbs (23.1 kg) with a compact footprint, making it practical to position and integrate into various installation scenarios and temporary setups.
