JBL AM7212/64-WH Two-way full range loudspeaker (white)
Description
JBL AM7212/64-WH Two-Way Full Range Loudspeaker
The AM7212/64-WH is a professional-grade two-way system built for sound techs and venue operators who need reliable high-output performance across midsize rooms, fixed installations, and touring rigs. Its trapezoidal cabinet design and rotatable waveguide provide flexible deployment options, while the white finish blends into corporate, educational, and performance spaces without visual compromise. This is a dependable workhorse speaker engineered to hold up night after night in the real world.
Audio Performance & Coverage
The system combines a 2262H 12-inch LF driver with dual voice coil and dual magnetic gap construction alongside a 2432H compression driver (1.5-inch exit, 3-inch voice coil) for articulate, transparent high-frequency reproduction. With a 1.8 kHz crossover point and 60 × 40° coverage pattern, the AM7212/64-WH maintains consistent throw and coverage across medium-distance applications, while its 36 Hz to 20 kHz frequency range reproduces the full spectrum from deep bass through crisp treble.
Build & Power Handling
The cabinet is constructed from 16 mm (5/8-inch) exterior-grade 11-ply Finnish birch plywood with a durable JBL DuraFlex finish designed to survive touring schedules and repeated installation cycles. Power handling reaches 1000 W continuous for the LF section (4000 W peak, 2-hour rating) and 100 W for the HF section, with 8-ohm nominal impedance and 96 dB SPL sensitivity (LF) / 115 dB SPL sensitivity (HF), enabling high-output operation in larger spaces with stable amplifier operation.
Key Features
- 2-way, full-range bi-amped or passive-switchable system
- 2262H 300 mm (12 in) low-frequency driver with dual voice coil and dual magnetic gap
- 2432H high-frequency 38 mm (1.5 in) exit, 75 mm (3 in) voice-coil compression driver
- Large format Progressive Transition waveguide, rotatable for vertical or horizontal orientation
- Nominal impedance 8 ohms with 96 dB SPL (LF) and 115 dB SPL (HF) sensitivity
- Frequency range 36 Hz to 20 kHz (−10 dB)
- Coverage pattern 60 × 40°; crossover at 1.8 kHz (passive)
- LF power handling 1000 W continuous (4000 W peak, 2 hrs); HF 100 W (400 W peak)
- 16 mm (5/8 in) exterior-grade 11-ply Finnish birch plywood with JBL DuraFlex finish
- 15 M10 threaded suspension points for secure rigging and installation
- 14-gauge steel grille with acoustically transparent foam protection
- White finish (−WH designation)
The AM7212/64-WH delivers the rugged construction, high output capability, and consistent coverage that sound operators and venue managers require for professional sound reinforcement in fixed and touring applications.
More Information
| Condition | New |
|---|
Reviews
At a Glance
The JBL AM7212/64-WH is a professional two-way loudspeaker engineered for midsize venues, touring rigs, and installed sound systems, combining a 12-inch dual-coil woofer with a compression driver for full-range articulate output and deep bass extension. Designed for performers and sound operators who demand reliable, high-output coverage night after night without compromise, this speaker handles 1000 W continuous power and delivers consistent 60 × 40° coverage across medium-throw applications. Built from rugged 11-ply Finnish birch plywood with a white DuraFlex finish, it's road-tested for the demands of touring and permanent installation in corporate and performance venues.
Who This Is For
Great for
- ✓ Live Performance
- ✓ Touring
- ✓ Installed Sound
- ✓ Corporate Events
Not the best pick for
- – Home Recording
- – Small Venue Intimacy
Skill level: Professional
Frequently Asked Questions
What is the frequency range and sensitivity of this speaker?
The AM7212/64-WH covers 36 Hz to 20 kHz (−10 dB) with 96 dB SPL sensitivity in the low-frequency section and 115 dB SPL sensitivity in the high-frequency section, enabling full-spectrum response and high output capability in medium to large venues.
Can this speaker be used in both touring and installed applications?
Yes. The cabinet is built from 16 mm exterior-grade 11-ply Finnish birch plywood with a durable JBL DuraFlex finish, designed to withstand repeated touring use, and includes 15 M10 threaded suspension points for secure rigging and permanent installation.
What is the power handling specification?
The low-frequency section handles 1000 W continuous (4000 W peak, 2-hour rating), while the high-frequency section handles 100 W continuous (400 W peak). The speaker operates at 8-ohm nominal impedance and is switchable for bi-amplified or passive operation.
What coverage pattern does this speaker provide?
The AM7212/64-WH features a 60 × 40° coverage pattern with a rotatable Progressive Transition waveguide, allowing vertical or horizontal orientation to suit medium-throw venues and installed sound applications with consistent, predictable audience coverage.
What drivers are inside this speaker?
The system combines a 2262H 12-inch low-frequency driver with dual voice coil and dual magnetic gap construction and a 2432H compression driver with a 1.5-inch exit and 3-inch voice coil, crossed over at 1.8 kHz for articulate high-frequency reproduction.
