JBL AM7212/95-WH Two-way full range loudspeaker (white)
Description
JBL AM7212/95-WH Two-Way Full Range Loudspeaker (White)
The AM7212/95 is a versatile professional loudspeaker engineered for installed sound, live reinforcement, and portable PA applications where consistent coverage and output are non-negotiable. Its compact trapezoidal enclosure and rotatable waveguide make it equally at home as a main or fill speaker, delivering clear articulation and controlled directivity across mid to large venues.
Audio Performance & Output
This two-way design pairs a 300mm (12") differential drive dual voice coil woofer with a 38mm (1.5") exit compression driver, crossing over at 1.4 kHz for seamless midrange integration. With 95 dB SPL sensitivity (1W @ 1m), the speaker reaches a maximum 126 dB-SPL (132 dB peak) from the low end and 133 dB-SPL (139 dB peak) from the high end, supplying sufficient gain for most fixed or touring installations.
Design & Build Quality
The enclosure features 16mm (5/8 in) exterior grade 11-ply Finnish birch plywood with heavy internal bracing, delivering rigidity without excess weight for transport and rigging. A 14-gauge steel grille lined with acoustically transparent foam protects the drivers while maintaining pristine audio clarity, and the DuraFlex finish ensures durability in demanding environments.
Key Features
- 2262H 300mm (12") differential drive dual voice coil and dual magnetic gap low-frequency driver
- 2432H 38mm (1.5") exit, 75mm (3") voice-coil compression driver
- 90° x 50° coverage pattern with rotatable waveguide for vertical or horizontal orientation
- 600W long-term power rating (2400W peak) in passive mode
- 1.4 kHz passive crossover frequency
- 95 dB SPL sensitivity (1W @ 1m)
- 126 dB-SPL (132 dB peak) low-frequency maximum SPL; 133 dB-SPL (139 dB peak) high-frequency maximum SPL
- Multi-ply birch enclosure with trapezoidal design and 15-degree side angles
- Bi-amp/passive switchable modes for flexible system configuration
- 15 M10 threaded attachment points for rigging and mounting
- 14-gauge steel grille with internal acoustically transparent foam lining
- JBL DuraFlex finish coating for weather and impact resistance
The AM7212/95-WH combines professional-grade components, robust construction, and application flexibility, making it a dependable choice for sound operators and venues requiring reliable full-range coverage night after night.
More Information
| Condition | New |
|---|
Reviews
At a Glance
The JBL AM7212/95-WH is a professional two-way loudspeaker engineered for live reinforcement, installed sound, and touring applications where consistent output and coverage are critical. Its 12-inch woofer and 1.5-inch compression driver deliver 126–133 dB SPL across the frequency spectrum with clear articulation and controlled directivity, making it equally capable as a main or fill speaker in mid to large venues. Built from 11-ply birch plywood with heavy internal bracing and a weather-resistant DuraFlex finish, it combines lightweight transport with the durability and reliability touring crews and permanent installations demand.
Who This Is For
Great for
- ✓ Live Performance
- ✓ Installed Sound
- ✓ Live Reinforcement
Not the best pick for
- – Home Recording
- – Studio Sessions
- – Practice
Skill level: Professional
Frequently Asked Questions
What makes the AM7212/95 different from other JBL full-range speakers like the PRX812W?
The AM7212/95 is engineered specifically for installed sound and permanent venue deployment, with a heavier 11-ply birch enclosure and more robust internal bracing than portable options. Its rotatable 90° × 50° waveguide and bi-amp/passive switchable configuration make it more flexible for fixed rigging and system design, whereas the PRX812W prioritizes portability for touring.
Can this speaker be used as both a main and a fill speaker?
Yes. The AM7212/95's controlled directivity, rotatable waveguide (vertical or horizontal mounting), and 90° × 50° coverage pattern allow it to serve as a main speaker or fill unit depending on placement and aiming. Its 15 M10 threaded attachment points support flexible rigging and mounting configurations.
What is the power handling and sensitivity rating?
The AM7212/95 has a 600W long-term power rating (2400W peak) in passive mode and 95 dB SPL sensitivity at 1W/1m. It reaches 126 dB SPL (132 dB peak) from the woofer and 133 dB SPL (139 dB peak) from the compression driver, providing sufficient output for most fixed or touring installations.
Is this speaker suitable for outdoor or weather-exposed installations?
The AM7212/95 features a JBL DuraFlex finish coating designed for weather and impact resistance, making it suitable for demanding outdoor and semi-outdoor environments. The 14-gauge steel grille with acoustically transparent foam lining also protects the drivers while maintaining audio clarity.
What is the crossover frequency and driver configuration?
The speaker pairs a 300mm (12 inch) differential drive dual voice coil woofer with a 38mm (1.5 inch) exit compression driver, crossing over at 1.4 kHz for seamless midrange integration. This two-way design delivers consistent coverage across the full frequency spectrum.
