JBL AM7215/66-WH Two-way full range loudspeaker (white)
Description
JBL AM7215/66-WH Two-way Full Range Loudspeaker (White)
The AM7215/66-WH is a professional-grade two-way loudspeaker engineered for consistent, controlled sound reinforcement in fixed installations and touring applications. Its trapezoid cabinet design and rotatable waveguide accommodate both vertical and horizontal mounting, making it adaptable to diverse venue layouts without acoustic compromise. Built on JBL's proven Differential Drive architecture, this speaker delivers authoritative low-end extension paired with articulate high-frequency projection for reliable performance night after night on stage or in permanent systems.
Acoustic Performance & Coverage
The 2265H dual voice coil driver (380 mm / 15 in) handles low frequencies with 98 dB SPL sensitivity at 1W, while the 2432H compression driver (38 mm exit, 75 mm voice coil) provides 114 dB SPL in the high frequencies. The 60 × 60° Progressive Transition waveguide ensures uniform directivity across the midrange and treble, producing consistent coverage patterns whether deployed in small rooms or larger venues. Frequency response holds ±3 dB from 40 Hz to 18 kHz, with full-spectrum extension down to 34 Hz at −10 dB—giving you the extended lows and articulate highs needed for live sound reinforcement.
Construction & Road Reliability
The cabinet is fabricated from multi-ply birch with DuraFlex finish and internal bracing for rigidity and durability in demanding environments. Fifteen M10 threaded attachment points enable secure flying or mounting, while the acoustically transparent foam-lined 14-gauge steel grille protects drivers without sonic coloration. Dual input options—NL4 Neutrik Speakon and CE-compliant barrier strip terminals—accommodate both touring and permanent installations, with switchable bi-amped or passive operation for maximum flexibility across different system configurations.
Key Features
- 2265H 380 mm (15 in) dual voice coil, dual magnetic gap Differential Drive LF driver
- 2432H compression driver with 38 mm exit and 75 mm voice coil
- LF sensitivity 98 dB SPL (1W @ 1m); HF sensitivity 114 dB SPL (1W @ 1m)
- Frequency response ±3 dB from 40 Hz to 18 kHz; 34 Hz to 20 kHz at −10 dB
- 60 × 60° coverage pattern via Progressive Transition waveguide
- 8 ohm nominal impedance; bi-amped or passive switchable configuration
- 1000 W continuous (4000 W peak, 2 hrs) LF; 100 W continuous (400 W peak) HF capacity
- Multi-ply birch with DuraFlex finish; heavily braced construction
- Fifteen M10 threaded attachment points for flying or fixed mounting
- NL4 Neutrik Speakon and barrier strip terminal inputs
- Rotatable waveguide for vertical or horizontal orientation
- 60 lbs (27.2 kg) weight; Mil-Std 810 environmental compliance; IP-x3 per IEC529
The AM7215/66-WH combines high output capability, controlled directivity, and flexible mounting in a proven professional design suited to both installed and temporary sound systems, making it a dependable choice for touring rigs and venue installations alike.
More Information
| Condition | New |
|---|
Reviews
At a Glance
The JBL AM7215/66-WH is a professional two-way loudspeaker built for live sound reinforcement in touring rigs and fixed installations, delivering authoritative bass and articulate treble with a consistent 60×60° coverage pattern. A rotatable waveguide and trapezoid cabinet make it adaptable to any room layout without acoustic compromise, while dual input options (Speakon and barrier strip) work equally well on a tour bus or permanently installed in a venue. Choose it when you need high output, reliability in demanding environments, and controlled directivity that projects clean, full-spectrum sound to every seat in the house.
Who This Is For
Great for
- ✓ Live Performance
- ✓ Touring
- ✓ Fixed Installation
- ✓ Large Venue Coverage
Not the best pick for
- – Home Recording
- – Practice
Skill level: Professional
Frequently Asked Questions
What kind of venues and applications is this speaker designed for?
The AM7215/66-WH is engineered for live performance, touring, and fixed installations in venues requiring consistent sound reinforcement across medium to large spaces. Its 60×60° coverage pattern, high output (98 dB LF / 114 dB HF sensitivity), and durable construction make it suited to touring rigs, permanent installations, and challenging acoustic environments.
How does the coverage pattern work, and can I rotate it?
The 60×60° Progressive Transition waveguide delivers uniform directivity across midrange and treble, ensuring consistent coverage from different listening positions. The waveguide is rotatable, so you can orient the speaker vertically or horizontally to match your venue layout without compromising acoustic performance.
What inputs and amplifier configurations does it support?
The AM7215/66-WH has dual input options: NL4 Neutrik Speakon connectors (touring standard) and CE-compliant barrier strip terminals (permanent installations). It can operate in bi-amped mode (separate amplifier channels for LF and HF) or passive mode, giving you flexibility across different system architectures.
What is the frequency response and how much power can it handle?
Frequency response is ±3 dB from 40 Hz to 18 kHz, with extension to 34 Hz at −10 dB. The LF driver handles 1000 W continuous (4000 W peak, 2 hours), and the HF driver handles 100 W continuous (400 W peak), making it suitable for high-output installations and touring applications.
Is this speaker rugged enough for touring and outdoor use?
Yes. The cabinet is multi-ply birch with DuraFlex finish and internal bracing for durability in demanding environments. It is Mil-Std 810 compliant and IP-x3 rated per IEC529, with 15 M10 threaded attachment points for secure flying or fixed mounting on any tour or installation.
