JBL AM7215/95-WH Two-way Full Range Loudspeaker

The AM7215/95-WH is a professional-grade two-way system built for reliable, consistent coverage in installed sound and live event applications. Its compact footprint and rotatable waveguide adapt quickly to horizontal or vertical mounting, while the DuraFlex finish white enclosure stands up to the abuse of touring and venue rigging. Built on JBL's proven compression driver topology, this speaker delivers articulate midrange clarity paired with authoritative low-frequency extension—the kind of straightforward performance you can count on night after night.

Design & Build Quality

The enclosure is constructed from heavily braced multi-ply birch finished in JBL's durable DuraFlex coating, with a 14-gauge steel grille internally lined with acoustically transparent foam for protection without sonic compromise. Fifteen M10 threaded suspension points provide secure rigging options, and the rotatable waveguide allows quick field adaptation between portrait and landscape mounting orientations.

Acoustic Performance & Power Handling

This system produces a 96 dB SPL @ 1W/1m sensitivity rating, enabling efficient operation with modest amplifier power while maintaining clean headroom. The 1.2 kHz crossover seamlessly integrates a dual voice coil, dual magnetic gap 15-inch woofer with a 1.5-inch compression driver, delivering 40 Hz–20 kHz (±3 dB) response and 128 dB continuous SPL (134 dB peak) in bi-amplified mode, or 124 dB continuous SPL (130 dB peak) in passive mode.

Key Features

15-inch low-frequency driver with dual voice coil and dual magnetic gap design
1.5-inch compression driver with 3-inch voice coil
Frequency response: 40 Hz – 20 kHz (±3 dB)
Frequency range: 34 Hz – 20 kHz (-10 dB)
System sensitivity: 96 dB SPL @ 1 watt/1 meter (passive mode)
Crossover frequency: 1.2 kHz
90 × 50° coverage pattern
8 Ohm nominal impedance
Long-term power rating: 600W passive (2400W peak, 100 hrs)
Maximum SPL: 128 dB continuous (134 dB peak) bi-amp; 124 dB continuous (130 dB peak) passive
Rotatable waveguide for vertical or horizontal orientation
Bi-amplified capable with separate amplification for high and low frequency drivers

The AM7215/95-WH combines rugged construction, efficient amplification, and predictable directional control—making it a dependable choice for touring venues, permanent installs, and live sound rigs where your system has to perform without excuses.
