JBL AWC159 All-Weather Compact 2-Way Coaxial Loudspeaker with 15 LF
Share
In stock
- SKU
- AWC159
Description
JBL AWC159 All-Weather Compact 2-Way Coaxial Loudspeaker with 15" LF
The AWC159 is a purpose-built outdoor speaker engineered for touring bands, festival rigs, and permanent outdoor stage installations. Its coaxial driver configuration delivers tight, focused sound across 90° x 90° coverage—ideal for both intimate outdoor venues and larger festival grounds. The heavily braced ABS enclosure and corrosion-resistant grille assembly are built to survive weeks on the road, extended UV exposure, humidity swings, salt spray, and temperature extremes without degrading tone or reliability.
Sound & Stage Performance
Operating across a 52 Hz – 20 kHz frequency range with ±3 dB response from 80 Hz – 20 kHz, the AWC159 reproduces your band's full mix with clarity and punch. High sensitivity of 98 dB (2.83V @ 1m) combined with maximum output of 125 dB SPL direct (peaks to 131 dB) gives you the headroom needed for outdoor stages and festival grounds; transformer taps provide flexible integration into 70V and 100V distributed systems at power levels from 38W to 300W for seamless setup with touring rigs.
Road-Ready Construction & Weather Sealing
Built to IP56 weatherproofing per IEC529 standards and verified against Mil Spec 810 for humidity, salt spray, temperature, and UV abuse, this speaker survives seasons in the field. A zinc-rich extra-thick powder-coated steel grille with 3-layer foam and mesh backing shields the 15" Kevlar-reinforced woofer and 1.5" compression driver, while the ABS with Glass heavily braced enclosure resists warping, denting, and environmental degradation through continuous touring and outdoor deployment.
Key Features
- 380 mm (15 in) woofer with Kevlar-reinforced cone and 75 mm (3 in) voice coil
- 38 mm (1.5 in) diaphragm compression driver with patented high-temperature polymer design
- Frequency Response: 80 Hz – 20 kHz (±3 dB); Range: 52 Hz – 20 kHz (-10 dB)
- 90° x 90° coverage pattern with Directivity Index of 9.7 dB (1 kHz – 16 kHz)
- Sensitivity: 98 dB (2.83V @ 1m, averaged 80 Hz – 20 kHz)
- Maximum SPL: 125 dB direct 8Ω (peaks 131 dB); 123 dB at 300W tap (peaks 129 dB)
- System power rating: 500 W (2000 W peak) 2 hrs.; 300 W (1200 W peak) 100 hrs.
- 1.5 kHz crossover with 4th order high-pass (24 dB/oct) and 2nd order low-pass
- Transformer taps: 70V (300W, 150W, 75W, 38W); 100V (300W, 150W, 75W)
- IP56 weatherproofing with 5° minimum downward aiming angle
- CE-compliant barrier strip terminals accepting up to 8 mm open lugs and 2.5 mm² (12 AWG) wire
- Includes color-matched U-bracket with M10 fine-thread attachment points plus M6 secondary safety point
The AWC159 combines proven coaxial architecture with genuine all-weather durability, delivering professional sound reinforcement in outdoor stages and touring environments where standard speakers would fail.
More Information
| Condition | New |
|---|---|
| Country of Manufacture | China |
Reviews
At a Glance
The JBL AWC159 is a weather-sealed 15-inch coaxial loudspeaker built for outdoor and semi-outdoor venues where standard gear won't survive—sports complexes, water parks, and harsh coastal environments. Sound techs and venue managers rely on its 98 dB sensitivity, 125 dB peak output, and IP56 weatherproofing (salt spray, UV, humidity rated) to handle both speech clarity and full-range music without compromise. Choose it when durability, intelligibility, and consistent output matter more than compact size.
Frequently Asked Questions
Is the AWC159 truly weatherproof, and what does IP56 rating actually mean?
Yes. IP56 certification per IEC529 means the speaker resists water jets and dust ingress; JBL also verified it against Mil Spec 810 standards for salt spray, UV, humidity, and temperature extremes. The zinc-rich powder-coated steel grille, 3-layer foam and mesh backing, and heavily braced ABS with glass enclosure all resist environmental degradation during continuous outdoor use.
What power options does it support, and do I need a transformer?
The AWC159 works in both low-impedance (8Ω direct) and distributed 70V/100V systems. Transformer taps include 70V options at 300W, 150W, 75W, and 38W, plus 100V taps at 300W, 150W, and 75W; choose the tap that matches your system voltage and available power.
Will it handle speech and music equally well?
Yes. The coaxial driver design maintains excellent intelligibility across a 90° x 90° coverage pattern, while 52 Hz–20 kHz frequency range and 98 dB sensitivity at 2.83V provide clarity for announcements and adequate presence for full-range music in large outdoor spaces.
What's included with mounting, and how is it installed?
The speaker includes a color-matched U-bracket with M10 fine-thread attachment points and an M6 secondary safety point for secure rigging. Barrier strip terminals accept up to 8 mm open lugs and 12 AWG wire; aim it minimum 5° downward for optimal coverage.
How loud can it get, and is it suitable for large venues?
Maximum output is 125 dB SPL direct (peaks to 131 dB at 8Ω), or 123 dB at 300W tap (peaks 129 dB). These levels suit large outdoor spaces like sports venues and water parks where coverage and durability are critical.
