JBL Control Hst-wh 5.25" Wide Coverage On-wall Speaker, Wht
Share
- Brand new in original box
- Full JBL manufacturer's warranty
- Free shipping in the continental US
In stock
- SKU
- CONTROL-HST-WH
Description
JBL Control HST-WH 5.25" Wide Coverage On-wall Speaker, White
The Control HST-WH is a compact, professional-grade on-wall speaker built for installation in commercial spaces, retail environments, and distributed audio systems where even coverage and mounting simplicity matter. Its shallow profile and included color-matched U-bracket make it straightforward to integrate into any interior without requiring extensive engineering. The wide horizontal and vertical coverage pattern delivers consistent output across large listening areas, making it reliable for venues that need dependable background and foreground audio without fuss.
Design & Installation
This speaker mounts flush to any wall with the included U-bracket, and its compact footprint (14.25 x 10.1 x 7.2 inches) fits cleanly into tight spaces without bulk. The IP54 and Mil-Std-810 ratings provide protection against moisture, humidity, and environmental stress—essential for retail, hospitality, and semi-outdoor applications where gear lives through real-world conditions night after night.
Audio Performance & Power
Built with a 5.25" CMMD woofer and dual fluid-cooled ¾" tweeters, the HST-WH delivers clean midrange and articulate highs across a 50 Hz–20 kHz frequency response with 88 dB sensitivity. The integrated 60-watt 70V/100V multi-tap transformer and 100W system power rating (400W peak) handle both line-level and high-impedance installations, while 108 dB maximum SPL with peaks to 114 dB ensures adequate output for medium to large rooms without breaking a sweat during performances and events.
Key Features
- 5.25" CMMD woofer with 25 mm voice coil
- Dual splayed ¾" fluid-cooled tweeters with CMMD-treated aluminum diaphragms
- 160 x 150° wide coverage pattern control
- 88 dB sensitivity (averaged 80 Hz–20 kHz)
- Maximum SPL: 108 dB direct into 8Ω, peaks to 114 dB
- 50 Hz–20 kHz frequency response
- Built-in 60W 70V/100V multi-tap transformer
- 100W system power rating (400W peak, 2 hrs per IEC)
- IP54 and Mil-Std-810 environmental ratings
- Removable locking 4-pin euro-block connector
- Aluminum grille with white finish
- Includes color-matched U-bracket for wall mounting
The Control HST-WH combines rugged environmental protection, straightforward installation, and reliable distributed-audio performance in a discreet on-wall package that operators and sound techs trust for consistent venue and event coverage.
More Information
| Condition | New |
|---|
Reviews
At a Glance
The JBL Control HST-WH is a compact, professional on-wall speaker built for commercial spaces, retail environments, and hospitality venues where consistent coverage and simple installation matter. Its wide 160 x 150° coverage pattern, IP54 environmental rating, and included U-bracket make it ideal for distributed audio systems that need reliable performance without drawing attention. Choose it for dependable background music and announcement coverage in medium to large rooms where mounting simplicity and weather resistance are priorities.
Who This Is For
Great for
- ✓ Commercial installations
- ✓ Retail environments
- ✓ Distributed audio systems
- ✓ Background music
- ✓ Hospitality venues
Not the best pick for
- – Home hi-fi listening
- – Critical monitoring
- – Live music performance
Skill level: Beginner · Intermediate · Advanced · Professional
Frequently Asked Questions
What does IP54 and Mil-Std-810 rating mean for this speaker?
IP54 protects against dust and water splash, while Mil-Std-810 certification ensures the speaker withstands environmental stress including humidity and temperature swings. These ratings make the HST-WH suitable for retail, hospitality, and semi-outdoor installations where standard speakers would fail.
Does this speaker work with both 70V and 100V systems?
Yes. The built-in 60-watt multi-tap transformer supports both 70V and 100V line-level installations, making it flexible for different distributed audio system designs.
What is the coverage pattern and how does it work in large rooms?
The 160 x 150° wide horizontal and vertical coverage pattern delivers consistent output across large listening areas. The speaker reaches 108 dB SPL (peaks to 114 dB) and handles up to 100W system power, suitable for medium to large commercial spaces.
What's included and how difficult is installation?
Installation includes a color-matched U-bracket for flush wall mounting, a removable locking 4-pin euro-block connector for audio, and no additional engineering required. The shallow 7.2-inch profile fits into tight spaces without bulk.
Can this speaker be used for live performance or home listening?
No. The HST-WH is designed for commercial distributed audio and background music in retail and hospitality—not for live sound reinforcement or critical home hi-fi listening.
Do I pay sales tax on this order?
We collect sales tax only on orders shipped to California. Orders shipped to any other US state are charged $0 sales tax at checkout when you buy direct from our website. On this item that is roughly $29 less out the door than the same listed price at a national retailer or on a marketplace. Marketplaces such as eBay, Reverb and Amazon collect sales tax in nearly every state as marketplace facilitators no matter who the seller is, so the same item at the same price costs less bought direct. Free US shipping and 30-day returns are included. Some states ask buyers to self-report use tax on out-of-state purchases.
