JBL Control SB2210-WH Dual 10" Compact Subwoofer, Wht
Description
JBL Control SB2210-WH Dual 10" Compact Subwoofer, White
The JBL Control SB2210-WH is a compact dual-driver subwoofer engineered for controlled low-frequency extension in installed sound and monitoring applications. Its 355 x 590 x 570 mm footprint and 23.31 kg weight make it deployable in tight spaces without sacrificing output capability. The rigid HIPS construction with 10% glass fill and IP-45 rating ensure reliable performance in demanding environments.
Audio Performance
Dual 250 mm woven fiberglass cone drivers with long-excursion design deliver a frequency range of 38 Hz–500 Hz (-10 dB) and usable response down to 48 Hz (-3 dB). With 95 dB sensitivity at 1W/1m and a maximum output of 122 dB SPL, this subwoofer achieves clean, controlled bass reinforcement across moderate-to-large venue sizes and distributed systems. For sound operators and venue techs, that sensitivity means the sub stays manageable on the mix without requiring heavy amplification to maintain consistent low end across a space.
Power & Connectivity
The unit handles 500W continuous pink noise (2000W peak) or 1000W continuous program material, supporting serious SPL demands night after night. An 8Ω nominal impedance (7.2Ω minimum at 160 Hz) and 60.0VRMS maximum input voltage provide straightforward integration into professional amplifier chains and powered speaker systems. Road-tested impedance specs mean no surprises when you're daisy-chaining rigs or mixing amp brands mid-tour.
Key Features
- Dual 250 mm (10 in.) woven fiberglass cone drivers with long-excursion design
- Frequency range (-10 dB): 38 Hz–500 Hz
- Frequency response (-3 dB): 48 Hz–95 Hz
- Sensitivity: 95 dB, 1W @ 1m in half-space
- Maximum SPL: 122 dB in half-space
- Power rating: 500W continuous pink noise (2000W peak); 1000W continuous program
- Compact dimensions: 355 x 590 x 570 mm (14 x 23.3 x 22.5 inches)
- Net weight: 23.31 kg (51.4 lb)
- HIPS construction with 10% glass fill and internal polyurethane co-mold
- IP-45 rating for water and dust resistance
- Nominal impedance: 8Ω; minimum impedance: 7.2Ω at 160 Hz
- Includes MTC-PC2 input panel cover, floor-standing feet, beveled washers, and 13 M6 mounting insert points
The Control SB2210-WH combines compact form factor with professional-grade output and durable construction, making it a dependable choice for installed bass reinforcement, touring sound systems, and fixed installations where reliable low end is non-negotiable.
More Information
| Condition | New |
|---|
Reviews
At a Glance
The JBL Control SB2210-WH is a compact dual 10-inch subwoofer delivering tight, controlled low-end extension from 48 Hz up, producing a clean 122 dB SPL maximum output in a footprint small enough for tight venue corners and distributed systems. Built for installed sound, live reinforcement, and monitoring setups, it pairs reliably with professional amplifiers and powered speaker chains without the bulk of larger single-driver units. Choose it when you need serious sub-bass articulation and dependable output in fixed installations where space and weight matter.
Who This Is For
Great for
- ✓ Live Performance
- ✓ Studio Sessions
- ✓ Installed Sound Systems
- ✓ PA/Venue Reinforcement
Not the best pick for
- – Portable DJ
- – Home Practice
Skill level: Intermediate · Advanced · Professional
Frequently Asked Questions
What makes the Control SB2210-WH compact, and where can it fit?
At 355 x 590 x 570 mm and 23.31 kg, it's sized for tight corners, under consoles, or distributed multi-zone installations where single larger subs won't fit. The 13 M6 mounting inserts and floor-standing feet allow flexible placement in venues, studios, and installed systems.
How does this sub integrate with my amplifier and speaker system?
It operates at 8Ω nominal impedance (7.2Ω minimum at 160 Hz) and accepts up to 60.0 VRMS input, making it straightforward to wire into standard professional amp chains. It handles 1000W continuous program material, so pairing with 500W–1000W continuous power per channel is typical.
What is the frequency response, and how does it handle articulate bass?
The dual 250 mm woven fiberglass cone drivers with long-excursion design deliver 38–500 Hz at -10 dB and 48–95 Hz at -3 dB, producing clean, articulate sub-bass without bloat. At 95 dB sensitivity, it achieves 122 dB SPL maximum in half-space, supporting moderate-to-large venue reinforcement and distributed monitoring.
Is the Control SB2210-WH weatherproof?
Yes, it carries an IP-45 rating and features rigid HIPS construction with 10% glass fill and internal polyurethane co-mold, making it reliable in humid, dusty, or outdoor-adjacent installed environments.
What's included with this subwoofer?
The unit ships with an MTC-PC2 input panel cover, floor-standing feet, beveled washers, and 13 M6 mounting insert points for secure installation in racks, venues, or studios.
