JBL PD6200/43-WH Two-way mid-high horn-loaded loudspeaker (white)
Description
JBL PD6200/43-WH Two-Way Mid-High Horn-Loaded Loudspeaker
The PD6200/43-WH is a compact, horn-loaded mid-high speaker engineered for consistent projection and clarity in fixed installations and touring applications. Its white powder-coated finish and compact footprint integrate seamlessly into distributed systems and under-balcony fills, while the rigging-ready design ensures quick deployment and reliable performance on the road or in permanent venues.
Design & Build Quality
Constructed with a powder-coated 14 gauge perforated steel grille backed by foam (or grille cloth on white units) and finished in DuraFlex, this speaker handles the demands of regular touring and venue installation. M10 threaded attachments provide secure rigging capability, and dual input options—Neutrik Speakon NL4 connectors plus CE-compliant covered barrier strip terminals—support both road deployments and permanent system integration without equipment swaps.
Audio Performance
The 8" CMCD-82H compression driver with integral dual voice coil handles midrange clarity, while the 1.5" exit 2432H compression driver with neodymium construction delivers articulate highs across a 40° × 30° coverage pattern. Output reaches 136 dB maximum SPL, and the 200 Hz to 18 kHz frequency response ensures full-range mid-high reproduction suitable for speech reinforcement, music systems, and front-of-house applications.
Key Features
- 8" CMCD-82H cone midrange compression driver with integral dual voice coil
- 1.5" exit 2432H high-frequency compression driver with neodymium magnet
- Frequency response: 200 Hz to 18 kHz
- Coverage pattern: 40° × 30°
- Maximum SPL: 136 dB
- 300 W passive mode (1200 W peak), 100 hour rating
- 8 ohm impedance with passive crossover and bi-amp mode capability
- Neutrik Speakon NL4 input plus CE-compliant covered barrier strip terminals
- Powder-coated 14 gauge perforated steel grille with foam or grille cloth backing
- DuraFlex finish
- M10 threaded attachments for rigging
- White finish option
The PD6200/43-WH combines proven compression-driver technology with flexible rigging and connectivity, making it a dependable workhorse for touring sound operators and venues requiring reliable mid-high projection in any configuration.
More Information
| Condition | New |
|---|
Reviews
At a Glance
The JBL PD6200/43-WH is a compact, horn-loaded mid-high speaker built for fixed installations and touring rigs where consistent projection and clarity matter most. Its dual compression drivers deliver 136 dB SPL with articulate highs and full midrange presence across a 40° × 30° coverage pattern, making it a reliable fill speaker for venues, under-balcony coverage, and distributed sound systems. Rigging-ready construction, dual input options (Speakon NL4 and barrier strip terminals), and a white powder-coated finish that resists road wear make this a professional-grade workhorse for sound crews and venue operators.
Who This Is For
Great for
- ✓ Live Performance
- ✓ Speech Reinforcement
- ✓ Touring
- ✓ Fixed Installation
Not the best pick for
- – Home Recording
- – Practice
Skill level: Professional
Frequently Asked Questions
What is the JBL PD6200/43-WH best used for?
This speaker is engineered for live-sound reinforcement, touring, fixed installation, and speech reinforcement applications. It serves as a mid-high fill speaker, under-balcony coverage unit, or component in distributed sound systems for venues and touring rigs. It is not designed for home recording or practice use.
What is the output and coverage pattern?
The PD6200/43-WH delivers a maximum SPL of 136 dB with a 40° × 30° coverage pattern, powered by an 8-inch CMCD-82H cone midrange compression driver and a 1.5-inch 2432H high-frequency compression driver with neodymium magnet. Frequency response spans 200 Hz to 18 kHz, suitable for full-range mid-high reproduction.
What connections and rigging options does it have?
The speaker includes Neutrik Speakon NL4 connectors and CE-compliant covered barrier strip terminals, accommodating both touring and permanent venue setups. M10 threaded attachments provide secure rigging capability, and the unit operates in 8 ohm passive mode or bi-amp mode with 300 W rating (1200 W peak).
Is the white finish durable for touring?
Yes; the white powder-coated finish uses DuraFlex coating backed by a 14-gauge perforated steel grille with foam or grille cloth backing, designed to withstand regular transport and installation use.
Can this speaker be used in a larger system?
Yes, it is engineered to integrate seamlessly into distributed PA systems and fixed installations. Dual input options and bi-amp capability allow flexible integration into multi-speaker venues and touring rigs where mid-high clarity and projection are critical.
