JBL PD6200/66-WH Two-way mid-high horn-loaded loudspeaker (white)
Description
JBL PD6200/66-WH Two-Way Mid-High Horn-Loaded Loudspeaker
The PD6200/66-WH is a compact, rotatable mid-high speaker system engineered for flexible deployment in live sound and installation environments. Its horn-loaded design delivers focused, controlled directivity with the efficiency needed for consistent coverage in venues ranging from small clubs to theater rigs.
Acoustic Design & Coverage
This system employs large-format PT™ Progressive Transition™ waveguides paired with an 8" CMCD cone midrange compression driver and 1.5" HF compression driver with neodymium magnet to achieve predictable 60 × 60° coverage across the 200 Hz to 18 kHz frequency range. The rotatable waveguide design allows quick orientation switching from horizontal to vertical without cabinet modification, adapting to both stage and overhead applications.
Build & Installation
Constructed from durable birch plywood with DuraFlex finish, the PD6200 resists road wear and environmental stress. M10 threaded rigging attachments provide secure suspension mounting, while NL4 speakON and barrier strip inputs support both bi-amp and passive operation modes, simplifying integration into existing touring or venue systems.
Key Features
- 8" CMCD cone midrange compression driver with dual voice coil design
- 1.5" exit HF compression driver with large-format neodymium magnet
- 60 × 60° coverage pattern for controlled directivity
- Frequency response: 200 Hz to 18 kHz
- Large PT™ Progressive Transition™ waveguides
- Rotatable waveguides for horizontal or vertical cabinet orientation
- Birch plywood construction with DuraFlex finish
- M10 threaded rigging attachments for suspension mounting
- NL4 speakON and barrier strip inputs
- Bi-amp and passive operating modes
This mid-high system delivers the precision, durability, and operational flexibility required in demanding touring and fixed installation applications.
More Information
| Condition | New |
|---|
Reviews
At a Glance
The JBL PD6200/66-WH is a compact, horn-loaded mid-high speaker built for touring and theater installs, delivering focused 60×60° coverage and predictable articulate response from 200 Hz to 18 kHz. Road-tough birch plywood construction and rotatable waveguides let you adapt quickly to stage or overhead placement without modifications. Choose this if you're running sound for medium-to-large venues and need reliable, efficient directivity that cuts through live environments.
Who This Is For
Great for
- ✓ Live Performance
- ✓ Touring
- ✓ Theater/Install
- ✓ Medium-to-large Venues
Not the best pick for
- – Home Studio
- – Small Bedroom Practice
Skill level: Professional
Frequently Asked Questions
What does the rotatable waveguide design do?
The waveguide rotates between horizontal and vertical orientation without requiring cabinet modification, letting you aim the 60×60° coverage pattern to match your stage layout or overhead rig instantly.
Can I use this in both passive and bi-amped setups?
Yes. The PD6200/66-WH supports both passive operation and bi-amp modes via dual voice coil design, with NL4 speakON and barrier strip inputs for flexible integration into existing touring or venue systems.
What is the frequency range and coverage pattern?
Frequency response spans 200 Hz to 18 kHz with a tight 60×60° coverage pattern, delivered through an 8-inch CMCD compression driver for midrange and 1.5-inch neodymium HF driver for articulate high-end response.
How does this stand up to touring and outdoor use?
The cabinet is built from durable birch plywood with DuraFlex finish and includes M10 threaded rigging attachments, designed to withstand road wear, environmental stress, and secure suspension mounting in demanding venues and installations.
How does this compare to other pro mid-high speakers?
The PD6200/66-WH sits alongside models like the JBL PD6200/64, d&b audiotechnik M4, and EAW QX5259 in the touring and install mid-high category; its rotatable design and large PT Progressive Transition waveguides offer operational flexibility and predictable coverage that touring rigs value.
