Martin Exterior Linear Pro-Graze, CTC, 1ft
Description
Martin Exterior Linear Pro-Graze CTC 1ft
The Martin Exterior Linear Pro-Graze is a compact LED linear fixture built for live event lighting, architectural projection, and venue installations where precise color control and dependable outdoor performance matter. Its slim 1.57-inch profile tucks into tight rigging spaces while delivering 800 lumens per foot of consistent, directable illumination. Engineered to survive touring schedules and permanent venue duty, this fixture combines professional-grade optics with industrial reliability you can count on night after night.
Optical Performance & Output
This fixture produces 800 lm/ft with a focused 9-degree beam angle, concentrating light exactly where it's needed on stage or facade without waste. Variable white LED technology offers three selectable color temperatures—2700K, 4000K, and 6500K—allowing you to shift warm tones to cool daylight within the same rig, essential for multi-genre venues and dynamic live shows.
Environmental Durability & Power Management
An IP66 rating ensures complete dust and water protection for outdoor and exposed venue applications, while vibration resistance specifications across multiple standards (IEC 60068-2-6, IEC 60068-2-64, and ANSI C136-31) guarantee stability through transport, setup, and high-energy performances. Power flexibility spans 12W, 10W, and 5W modes with ASHRAE compliance, drawing from standard 100-277V AC, 50/60 Hz circuits and dissipating just 41 BTU/hr.
Key Features
- 12 x 1W variable white LEDs per fixture
- 800 lumens per foot output
- 9-degree beam angle for focused directional light
- Three color temperature options: 2700K, 4000K, 6500K
- IP66 environmental rating for dust and water protection
- DMX control with Remote Device Management (RDM) capability
- 8-pin custom connectors with 4 kV surge protection
- Multiple power modes: 12W, 10W, 5W with ASHRAE compliance
- Input voltage: 100–277V AC nominal, 50/60 Hz
- Compact dimensions: 1.57" W × 2.67" H; 1.9 lbs weight
- Vibration resistance: 1.0g Sinusoidal, 0.7g RMS Random, 3.0g ANSI
- Maximum heat dissipation: 41 BTU/hr
The Pro-Graze delivers pro-grade color consistency and road reliability in a fixture that disappears visually while giving you complete control over light output and tone—essential for touring rigs and permanent venue installations alike.
More Information
| Condition | New |
|---|
Reviews
At a Glance
The Martin Exterior Linear Pro-Graze is a compact 1-foot LED fixture built for architectural and landscape lighting with 800 lumens per foot, three selectable color temperatures (2700K to 6500K), and IP66 weatherproofing for outdoor reliability. Sound and lighting technicians running live events or permanent installations benefit from its focused 9-degree beam angle, DMX control with RDM capability, and ability to shift color tone on the fly without swapping fixtures. Choose this for venues, outdoor stages, or architectural accent lighting where durability, precise light control, and pro-grade color consistency matter.
Frequently Asked Questions
What does IP66 rating mean for outdoor use?
IP66 provides complete protection against dust ingress and powerful water jets from any direction, making this fixture safe for exterior mounting, wet environments, and high-pressure washdown. The fixture also meets vibration resistance standards (IEC 60068-2-6, IEC 60068-2-64, ANSI C136-31) for stability in exposed, dynamic locations.
Can I change color temperature during an event or shoot?
Yes, the fixture offers three selectable color temperatures—2700K (warm), 4000K (neutral), and 6500K (daylight cool)—and supports DMX control with Remote Device Management (RDM) capability, allowing you to shift tones remotely or via controller without physical adjustment.
What are the power options and electrical requirements?
The fixture operates at 100–277V AC, 50/60 Hz and offers three power modes: 12W, 10W, and 5W, all ASHRAE-compliant with minimal heat output (41 BTU/hr). This flexibility lets you run it on standard building power and scale consumption based on your installation needs.
How bright is this fixture and what is its beam pattern?
The fixture delivers 800 lumens per foot with a tightly focused 9-degree beam angle, concentrating light precisely where needed for architectural accent or landscape detail lighting without spill.
What connectors and surge protection does it have?
The fixture uses 8-pin custom connectors with 4 kV surge protection, ensuring reliable outdoor signal and power transmission in electrically challenging environments.
