Martin MAC Aura Raven XIP in EPS
Description
Martin MAC Aura Raven XIP in EPS
The Martin MAC Aura Raven XIP is a compact yet powerful moving head that balances extreme output with genuine portability. Its dual-engine design—combining a high-intensity beam engine with an independent RGB aura backlight system—delivers visual depth that larger fixtures struggle to match, making it essential for touring productions, festival rigs, and permanent installations where versatility and punch matter equally.
Output & Optical Performance
The 27,000-lumen beam engine achieves exceptional brightness across a 6 to 51-degree zoom range, ensuring tight spot work and broad coverage without fixture changes. The 70-watt aura LED engine drives 234 individual RGB LEDs across the backlight, creating dimensional color separation and texture that enriches the beam itself—a significant advantage for texture-heavy programming and live visual impact.
Control & Operational Reliability
Native support for DMX, Art-Net, sACN, and Martin P3 protocols ensures seamless integration into any control ecosystem, from traditional wired rigs to networked systems. The IP54 weatherproof rating and 50,000-hour LED lifetime mean this fixture handles touring cycles and outdoor deployment without compromise, while dual 1/4-turn omega bracket points plus M12 threaded mounting provide secure, flexible rigging options that survive repeated load-in and breakdown cycles.
Key Features
- 27,000 lumens peak output from beam LED engine
- 6 to 51-degree motorized zoom range
- 830W beam LED engine power; 70W aura LED engine power
- RGBL (Red, Green, Blue, Lime) LED type for expanded color space
- 234 individual RGB aura backlight LEDs
- 50,000+ hour LED lifetime to 70% luminous output
- IP54 weatherproof rating for indoor/outdoor use
- 3,478 BTU/hr thermal dissipation capacity
- 343mm front lens diameter
- DMX, Art-Net, sACN, and Martin P3 protocol support
- Dual omega bracket mounting plus M12 threaded rigging point
The Raven XIP combines hard-touring durability with creative flexibility, making it a fixture that justifies its place on any production's equipment list and earns its weight in touring trucks night after night.
More Information
| Condition | New |
|---|
Reviews
At a Glance
The Martin MAC Aura Raven XIP is a compact 27,000-lumen moving head designed for touring, festival, and permanent installation work where output and visual impact cannot be compromised. Its dual-engine design—a high-intensity beam paired with an independent RGB aura backlight system—delivers dimensional color and texture that enriches programming, while the 6 to 51-degree zoom range handles everything from tight spots to broad washes without fixture swaps. IP54 weatherproofing, 50,000-hour LED life, and multi-protocol support (DMX, Art-Net, sACN, Martin P3) make this a road-ready workhorse for production crews and venues that demand reliability and creative flexibility.
Who This Is For
Great for
- ✓ Live Performance
- ✓ Touring
- ✓ Festival Production
- ✓ Permanent Installation
Not the best pick for
- – Home Recording
- – Practice
Skill level: Professional
Frequently Asked Questions
What is the zoom range and beam spread?
The Raven XIP features a motorized 6 to 51-degree zoom range, allowing tight spot work at narrow angles and broad coverage at wider settings without requiring fixture swaps. This versatility reduces the number of different fixtures needed in a rig.
How does the aura LED engine work with the main beam?
The dual-engine design combines an 830W beam LED engine with an independent 70-watt RGB aura backlight system of 234 individual LEDs. The aura engine creates dimensional color separation and texture that enriches the beam itself, adding visual depth that larger single-engine fixtures struggle to match.
What control protocols does it support?
The Raven XIP natively supports DMX, Art-Net, sACN, and Martin P3 protocols, ensuring seamless integration into traditional wired rigs, networked systems, and mixed control ecosystems.
Is this fixture suitable for outdoor use?
Yes. The IP54 weatherproof rating and 3,478 BTU/hr thermal dissipation capacity enable reliable outdoor deployment. Combined with a 50,000+ hour LED lifetime and dual rigging points, this fixture is built for touring productions and permanent outdoor installations.
What mounting options are available?
The fixture includes dual 1/4-turn omega bracket mounting points plus an M12 threaded rigging point, providing flexible and secure mounting for truss, floor stands, and permanent installation hardware.
