Martin MAC Aura Raven XIP white in EPS
Description
Martin MAC Aura Raven XIP White in EPS
The Martin MAC Aura Raven XIP is a compact yet powerful LED moving head fixture engineered for touring, theater, and outdoor installations where reliability and output matter equally. Its white finish and weatherproof XIP technology make it equally at home on outdoor stages or in demanding indoor environments. Built for fast setup and intuitive control, this fixture delivers professional-grade light quality without the bulk of traditional spot fixtures.
Optical Performance & Output
This fixture produces 27,000 lumens with a 343 mm front lens and flexible 6 to 51-degree zoom range, allowing precise beam shaping from tight spots to broad washes. The 2,000K to 12,850K color temperature range and dual CRI modes (75 standard, 86 optimized) deliver saturated colors and skin-tone accuracy across any application—critical for both concert lighting and broadcast work.
Light Engine & Control Architecture
The fixture's light engine combines 37 × 40W RGBL LEDs for the main output with 234 × 0.25W RGB LEDs in the Aura backlight system, creating dimensional color mixing and edge effects impossible with single-source fixtures. Control is seamless via DMX, Art-Net, sACN, and Martin P3, with NFC interface support for the Companion Mobile App—eliminating the need for physical consoles for basic configuration.
Key Features
- 27,000 lumens output with 343 mm front lens
- 6 to 51-degree motorized zoom range
- Color temperature: 2,000K to 12,850K continuously variable
- CRI 75 (default) or CRI 86 (optimized mode)
- 37 × 40W RGBL main LED array
- 234 × 0.25W RGB Aura backlight LEDs
- DMX, Art-Net, sACN, and Martin P3 control protocols
- NFC-enabled configuration via Companion Mobile App
- XIP weatherproof technology for outdoor use
- Compact dimensions: 528 mm width × 588 mm height × 241 mm depth (head)
- FSC-certified cardboard packaging with recycled EPS inner protection
The Raven XIP combines output and color fidelity with genuine weather resistance and networked control flexibility—a fixture that scales from single-unit theater rigs to large-scale tour deployments without compromise.
More Information
| Condition | New |
|---|
Reviews
At a Glance
The Martin MAC Aura Raven XIP is a compact LED moving head fixture built for touring, theater, and outdoor stages where reliability and raw light output drive the show. Its 27,000 lumens, weatherproof XIP technology, and dual color-mixing engines (main array plus Aura backlight) deliver saturated hues and skin-tone accuracy in any venue—indoor theater or open-air festival. Fast setup, networked control via DMX/Art-Net/sACN, and NFC-enabled mobile configuration make this fixture dependable for touring rigs and broadcast work without the footprint of traditional spots.
Who This Is For
Great for
- ✓ Live Performance
- ✓ Touring
- ✓ Theater
- ✓ Broadcast
- ✓ Outdoor Installations
Not the best pick for
- – Home Recording
- – Practice
Skill level: Intermediate · Advanced · Professional
Frequently Asked Questions
What makes the Raven XIP suitable for outdoor installations?
The fixture features XIP weatherproof technology and a white finish designed for outdoor stages and demanding environmental conditions. It maintains full optical and color performance in exposed settings where traditional fixtures would fail.
Can I control this fixture without a dedicated lighting console?
Yes. The Raven XIP supports DMX, Art-Net, sACN, and Martin P3 control protocols, and includes NFC support for the Companion Mobile App, allowing basic configuration and control directly from a mobile device without a physical console.
What color temperature range and CRI modes does it offer?
The fixture provides a continuously variable 2,000K to 12,850K color temperature range with two CRI modes: CRI 75 (standard) and CRI 86 (optimized for accurate skin tones). This dual-mode approach ensures color fidelity for both concert and broadcast applications.
How does the dual LED system create dimensional effects?
The fixture combines 37 × 40W RGBL LEDs in the main light engine with 234 × 0.25W RGB LEDs in the Aura backlight system. This arrangement enables color mixing and edge effects that single-source fixtures cannot achieve, adding visual depth to lighting design.
What is the zoom range and beam flexibility?
The motorized 6 to 51-degree zoom range allows precise beam shaping from tight spotlighting to broad washes, giving operators flexible control over beam size and throw distance in any venue.
