Seymour Duncan Pickgrd Assy, Dave Murray, Pearloid Pickup

Share
Pin it
Login to earn Guitar Bucks for sharing!
  • Brand new in original box
  • Full Seymour Duncan manufacturer's warranty
  • Free shipping in the continental US

In stock

SKU
11550-07
Pay by credit or debit card at checkout
Or check out instantly with
No sales tax on orders shipped outside California Most national retailers and online marketplaces now collect sales tax in nearly every state. Shipping outside California keeps roughly 6–10% in your pocket. Learn more

Wiring: ships from Seymour Duncan with a 4-conductor lead (coil splitting and phase switching ready).

Members save 5% in the cart. Sign in or create a free account - it takes a minute and the discount is taken off at checkout.
Description

Seymour Duncan Pickgrd Assy, Dave Murray, Pearloid Pickup

This Dave Murray signature pickguard assembly is a stage-ready, high-output solution for Strat players who want proven tone without sourcing parts. The pearloid finish stands out under lights, while the pre-loaded pickup configuration delivers the aggressive character that cut through on arena stages. Built by Seymour Duncan in Santa Barbara, this assembly arrives tested and ready to drop into your instrument—no hunting for matching components, no wiring headaches.

Pickup Configuration & Tone

Hot Rails pickups in the neck and bridge positions pack tight, high-output response with rejection against hum and feedback, while the JB Jr. middle pickup stays articulate for cleaner passages and single-coil voicings. All pickups feature 4-conductor splittable lead wire and vacuum wax potting, so you can coil-split for tonal flexibility and count on rock-solid performance in high-gain live rigs where microphony and feedback kill takes.

Build Quality & Installation

The assembly fits the 11-hole 'USA' pickguard pattern standard to post-1964 Stratocasters and pairs with high-quality Bourns potentiometers and a 5-way pickup selector for reliable, consistent operation night after night. Hand assembly in Santa Barbara ensures attention to detail, and installation instructions are included to guide the setup process.

Key Features

  • Pearloid finish pickguard with 11-hole USA Strat pattern
  • Hot Rails neck pickup with small ceramic magnet
  • Hot Rails bridge pickup with small ceramic magnet
  • JB Jr. middle pickup
  • 4-conductor splittable lead wire on all pickups
  • Vacuum wax potted construction for noise rejection
  • Bourns volume and tone potentiometers
  • 5-way pickup selector switch
  • Fits most post-1964 Stratocasters
  • Hand built in Santa Barbara, California
  • Installation instructions included
  • Personalized special stickers included

This complete assembly cuts through sourcing delays and assembly guesswork, delivering Dave Murray's signature high-output character as a finished, tested package ready for gigs.

More Information
Condition New
Reviews
Write Your Own Review
You're reviewing: Seymour Duncan Pickgrd Assy, Dave Murray, Pearloid Pickup
Your Rating:
loader
Loading...

You submitted your review for moderation.

This form is protected by reCAPTCHA - the Google Privacy Policy and Terms of Service apply.

At a Glance

This Dave Murray signature pickguard assembly drops into any post-1964 Stratocaster with 11-hole routing and delivers high-output, aggressive tone straight out of the box—no component hunting or wiring required. The Hot Rails neck and bridge pickups paired with a brighter JB Jr. middle pickup capture that legendary Yngwie-era Strat character with tight, noise-free response that cuts through live mix. Hand-built in Santa Barbara with vacuum wax potting and 4-conductor leads for coil-splitting mods, it's a road-ready solution for gigging players and collectors chasing classic high-gain Strat aggression.

Frequently Asked Questions

What Stratocasters does this pickguard assembly fit?

This assembly is designed for post-1964 Stratocasters with the 11-hole USA Strat pattern routing. It comes with installation instructions to guide the mounting process on compatible models.

Can I modify the pickups for coil-splitting later?

Yes. All three pickups feature 4-conductor splittable lead wire, so you can add coil-splitting switches or mods without rewiring the pickups themselves.

What's the tone character of this assembly?

The Hot Rails neck and bridge pickups deliver tight, high-output aggression ideal for high-gain work, while the JB Jr. middle pickup provides a brighter, more articulate single-coil texture. All three are vacuum wax potted to reject noise and microphony in demanding applications.

What's included with the assembly?

The complete pickguard assembly includes the pearloid pickguard, three pickups, Bourns potentiometers, 5-way selector switch, installation instructions, and personalized stickers.

Is this hand-assembled?

Yes. This assembly is hand-built in Santa Barbara, California, and arrives tested and ready for installation.

Do I pay sales tax on this order?

Sales tax is collected only on orders shipped to California; orders shipped to any other US state are not charged sales tax at checkout when you buy direct from our website. At a typical 7% rate that is an estimated $29 less at checkout than the same listed price on a marketplace, which collects sales tax as the facilitator in most states. Buyers remain responsible for any use tax their state applies. Free US shipping and 30-day returns are included.
