Martin ELP CL IP Full color LED Ellipsoidal Light Body White
Share
In stock
- SKU
- 9045122816
Description
Martin ELP CL IP Full Color LED Ellipsoidal Light Body White
The Martin ELP CL IP is a professional-grade full-color LED ellipsoidal fixture built for touring, theatre, and permanent installation environments where precision light output and IP65 durability are non-negotiable. Its compact white housing integrates seamlessly into modern rigs while delivering exceptional color mixing capability and consistent beam control across variable throw distances.
Light Output & Color Performance
This fixture produces 6,900 lumens in High Output mode (85 CRI) or 5,900 lumens in High Quality mode (90 CRI), with a native color temperature of 6,000K open white. The RGBLA color mixing system and 26 color presets deliver seamless color transitions across the 2000–10000K range, enabling both tungsten-balanced warm tones and daylight-corrected cool tones with precise 16-bit dimming control for refined cue execution on stage.
Build Quality & Environmental Protection
IP65 compliance protects against moisture ingress and complete dust contamination, while C3 corrosion resistance ensures longevity in humid or salt-air environments—critical for reliable touring. The fixture weighs 12.2 kg (body only) and measures 644 × 255 × 255 mm, with bracket-mounted height reaching 527 mm—compact enough for tight touring rigs yet robust enough for road reliability across seasons and venues.
Key Features
- 6,900 lumens (High Output, 85 CRI) / 5,900 lumens (High Quality, 90 CRI)
- RGBLA color mixing with 26 color presets
- Color temperature range 2000–10000K
- IP65 moisture and dust protection with C3 corrosion resistance
- Electronic dimming 0–100% with four dimming curve options
- 16-bit dimming resolution
- Variable-speed strobe and pulse effects
- 5-pin DMX/RDM and Neutrik True1 In/Thru connectivity
- Interchangeable static lens tubes: 19°, 26°, 36°, 50° beam angles
- Available in black and white housing options
- 1000 BTU/hr heat dissipation at full intensity
- Weight: 12.2 kg body only; compact form factor 644 × 255 × 255 mm
The Martin ELP CL IP combines high lumen density, environmental resilience, and flexible optics to deliver show-grade lighting that stands up to tour demands and maintains color fidelity night after night.
More Information
| Condition | New |
|---|
Reviews
At a Glance
The Martin ELP CL IP is a professional full-color LED ellipsoidal fixture built for touring, theatre, and installed venues that demand IP65 durability and precise beam control. Live sound and lighting crews rely on its 6,900-lumen output, RGBLA color mixing, and interchangeable lens tubes to deliver consistent light across variable throw distances—all in a compact, corrosion-resistant white housing. Choose it when your production cannot tolerate equipment failure due to moisture, dust, or salt air, and when color fidelity and throw flexibility are mission-critical.
Frequently Asked Questions
What beam angles does the Martin ELP CL IP offer?
The fixture includes interchangeable static lens tubes available in 19°, 26°, 36°, and 50° beam angles, allowing you to adapt throw distance and coverage to your stage layout or studio setup without changing fixtures.
How does the color temperature range work?
The RGBLA color mixing system spans 2000–10000K, with 26 color presets and electronic dimming at 16-bit resolution, enabling seamless transitions from warm tungsten tones to cool daylight-corrected whites across variable production scenarios.
Is this fixture suitable for outdoor touring and wet environments?
Yes. IP65 compliance protects against moisture and dust ingress, and C3 corrosion resistance ensures longevity in humid or salt-air environments, making it ideal for outdoor touring and permanent installations in challenging climates.
What lighting outputs are available?
The fixture produces 6,900 lumens in High Output mode (85 CRI) or 5,900 lumens in High Quality mode (90 CRI), with a native color temperature of 6,000K, giving you the flexibility to prioritize brightness or color rendering depending on your production demands.
What control and connectivity options are included?
The Martin ELP CL IP features 5-pin DMX/RDM control and Neutrik True1 In/Thru connectivity for power and data, with electronic dimming (0–100%), four dimming curve options, variable-speed strobe, and pulse effects for comprehensive production control.
